Dynaudio BM6A | 2-Way 100W 7 Inch Active Studio Monitor

Dynaudio BM6A 2-Way 100W 7 Inch Active Studio Monitor

The BM 6A features an electronic 4th order phase-aligned crossover with a crossover point at 2.2kHz, which feeds two high performance discrete MOSFET amplifiers rated at 100W each.
The low frequency section is driven by a low frequency equalizer offering a choice between extended, critical damped response or more conventional higher Qt response for more level but less low frequency output. Included in the electronics is a complex protection circuit, which helps to prevent accidental damage to the drivers, yet still providing maximum transient response.
The BM 6A is housed with an elegant matte cabinet with radius edged construction on the front baffle to reduce boundary effects and improve overall sound quality.

Key Features

• High-resolution 1.1" soft dome tweeter, pure aluminum voice coil
• 7" woofer, pure aluminum voice coil
• 2 channel high grade 100-Watt RMS amplifier
• 118dB SPL max. SPL
• Frequency response of 41Hz to 21kHz
• HF & LF analog trim filters

Technical Specifications

System: 2-way Active Nearfield Monitor
Frequency Response: 41 Hz - 21 kHz
Max SPL 1m, pair (IEC Long Term): 118 dB RMS
Max SPL 2m, 5.1 (IEC Long Term): 119,5 dB RMS
Input level for 85 dB SPL @ 1m (+4/-10): -12 dBu RMS / -28 dBu RMS
Input level for max peak SPL (+4/-10): +16 dBu peak / -1 dBu peak
Power consumption: Idle: 25 W / Max: 200 W
Amplifier power: Tweeter: 100 W / Woofer: 100 W
Resonance Frequency: 49 Hz
Internal Cabinet Volume: 9,5 liters
Principle: Bass reflex
Crossover Frequencies: 2200 Hz
Crossover Slope: 24 dB/oct
Tweeter: Esotec 28 mm soft dome, rear chamber, Magnetic fluid. 4 mm die-cast alu front,
Woofer: 17 cm, 75 mm pure alu wire voice coil, One piece molded polypropylene cone
Weight: 11 kg
Dimensions (WxHxL): 217 x 338 x 321 mm
