Dynaudio LYD 7 7-Inch Nearfield Monitor, Black
Description
Description
Dynaudio LYD 7 7-Inch Nearfield Monitor, Black
A 7in personal reference monitor, designed from the ground-up to bring supreme precision to your mixes
This monitor uses sophisticated DSP to extend or its curtail low-frequency response by 10Hz, while Position and Sound Balance controls let you fine-tune for total neutrality in your environment. Its larger 7in woofer helps extend bass, while the low-mass aluminium voice-coil, vented ferrite magnet and MSP driver take care of precision.
Key Features
- Nearfield Monitor with 7" Woofer
- Bi-amped speaker design with 2 x 50W and state-of-the-art Class-D amplification
- Bass extension to extend or curtail the low end frequency response
- Two different tunings: one for free standing and one designed for speakers within 50 cm of wall
- Sound balance to influence the overall response of the speaker
- Made in Denmark
Technical Specifications
Max SPL (1m, pair)
109dB
Principle
Bass reflex
Crossover Frequency
4.3kHz
Tweeter
1in soft dome
Mid
N/A
Woofer
7in
Dimensions (W x H x D)
186 x 320 x 296mm
Weight
8kg
Sensitivity (85dB @ 1m, free field)
+6dB: 50mV
0dB: 100mV
-6dB: 200mV
Power (Tweeter/Woofer)
HF 50W/LF 50W
Type
Class-D
Power consumption standby
<0.5W
Power consumption max.
100W
Input voltage
90 - 264V AC, 50 - 60Hz
Inputs
XLR balanced / RCA unbalanced
Outputs
N/A
Cut-off frequencies -6dB limits
Bass extension +10Hz: 65Hz - 21kHz
Bass extension 0Hz: 55Hz - 21kHz
Bass extension -10Hz: 45Hz - 21kHz
Free field frequency response
55Hz - 19kHz
