EBS Reidmar 502 500W 2-Ohm Bass Amplifier Head
EBS Reidmar 502 500W 2-Ohm Bass Amplifier Head
The EBS Reidmar 502 handles a 2-ohm load so it can drive two 4-ohm cabinets simultaneously. To our knowledge, it is the first lightweight amp in the 500W-range that truly does that. And it does it with conviction too.
Efficient power handling
Due to EBS clever developed Soft-clip design, the Reidmar 502 makes efficient use of all the power at hand. That means more punch and a lot less compressed sound than with lightweight amplifiers using automatic limiters to prevent clipping. It keeps the bass tone from sounding muddy and preserve the lows solid on higher volumes.
Analog preamp
The preamp, featuring EBS renowned built-in compressor and a 4-band EQ-section, gives you full control. Use it to bring out anything from a warm nice low end, brilliant highs and mids that cut through the mix when you need it.
Some other features include:
Onboard adjustable compressor.
Effects loop (send and return)
Balanced XLR-out for live and studio use (with pre/post EQ switch and Ground Lift)
Line out
Headphones output
Perfect Companions
If you prefer a compact rig, match the Reidmar 502 with a couple of EBS ClassicLine mini-size 112 cabinets, the new ClassicLine 210 or the NeoLine mini-size cabinets (for more clarity and punch).
For a more impressive look or when the gig calls for an even more powerful bass tone, you can use the Reidmar 502 with a couple 4-ohm, 410 cabinets as well. A nice, well-balanced setup, that hits a sweet spot between power and portability is to use it with a NeoLine 210 and 212 cabinet together.
Key Features
- Type: Analog Preamp, 2-ohm D-Class Power Amp
- Built-in Compressor/Limiter
- Extremely Powerful 4-band EQ
- Effects loop
- Character filter.
- Balanced XLR-Out with Pre/Post EQ switch and Ground Lift.
- Line and Headphones Out
Technical Specifications
Input Impedance
2 Mohms
Gain Range
-00 - +30 dB
Character Filter
Shelving, High/Low Pass, +7 dB @ 40 Hz, -2 dB @ 800 Hz,
+3 dB @ 10 kHz
Tone Controls
Bass Shelving +/-18 dB @ 60 Hz
Mid Bandpass Filter 100 - 6000 Hz +/- 12-15 dB
Treble Shelving +/-18 dB @ 6 kHz
Bright Shelving +15/-0 dB @ 10 kHz
Balanced Output
-10 dBv, Pre/Post EQ, GND Lift
Output Power
250 W RMS / 470 W Dynamic Output @ 2 and 4 ohms load
Dimensions (WxDxH)
12.8 x 9.8 x 3.0” (32.5 x 25 x 7.5 cm)
Weight
3.3 kg (7.3 lbs.)
