Electro-Voice LH1-UC30E 30W Music Horn Loudspeaker
Music Horn Loudspeaker 30W
Technical Specifications
Maximum power
45 W
Rated power (PHC)
30 W
Power tapping
30 / 15 / 7.5 / 3.75 W
Sound pressure level at rated power / 1 W (1 kHz, 1 m)
115 / 100 dB (SPL)
Sound pressure level at rated power / 1 W (1 kHz, 4 m)
100 / 86 dB (SPL)
Effective frequency range (- 10 dB)
212 Hz to 20 kHz
Opening angle at 1 kHz / 4 kHz (-6 dB)
Horizontal 68Ā° / 68Ā°
Vertical 100Ā° / 120Ā°
Rated impedance
70 V / 100 V
30 W: 167 Ohm / 333 Ohm
15 W: 333 Ohm / 667 Ohm
7.5 W: 667 Ohm / 1334 Ohm
3.75 W: 1334 Ohm / 2668 Ohm
Connector
6-pole screw terminal
* Technical performance data acc. to IEC 60268-5
Dimensions (H x W x D)
255 x 370 x 354 mm (10.04 x 14.56 x 13.93 in)
Weight
5.5 kg (12.45 lb)
Color
Light grey (RAL 7035)
Material (horn / bracket)
ABS / Aluminum
Cable diameter
6 mm to 12 mm (0.24 in to 0.47 in)
Operating temperature
-25 ĀŗC to +55 ĀŗC (-13 ĀŗF to +131 ĀŗF)
Storage and transport temperature
-40 ĀŗC to +70 ĀŗC (-40 ĀŗF to +158 ĀŗF)
Relative humidity
<95%
