EMG 35P 5-String Active Ceramic Bass Guitar Pickup

EMG 35P 5-String Active Ceramic Bass Guitar Pickup

The EMG 35P is a high-quality active pickup designed specifically for 5-string bass guitars with narrow string spacing. Encased in a 3.5-inch (89mm) extended range housing, this pickup features a unique configuration with the treble magnet positioned closer to the neck, similar to designs found in Spector or Yamaha basses. This design choice enhances the tonal characteristics, providing a wide sonic palette suitable for both classic and modern bass sounds.

Utilizing ceramic magnets paired with short, squat coils, the EMG 35P delivers brilliant high-end articulation, warmth, and a powerful low-end punch. This combination ensures that your bass lines cut through the mix with clarity and presence. Many professional bassists prefer this pickup for its natural presence, superior dynamics, and low noise performance, making it a reliable choice for various playing styles and genres.

Installation is made effortless with EMG's exclusive solderless wiring system. The package includes all necessary components, such as a 25k volume pot, 25k tone pot, battery bus, stereo output jack, mounting screws, and various cables, ensuring a seamless setup process. This user-friendly design allows both seasoned musicians and beginners to upgrade their instrument's sound with minimal hassle.

Key Features

• Designed for 5-string basses with narrow string spacing
• Extended range housing measuring 3.5 inches (89mm)
• Treble magnet positioned closer to the neck for enhanced tonal response
• Ceramic magnets coupled with short, squat coils for brilliant high-end articulation and powerful low-end punch
• Low noise performance with natural presence and superior dynamics
• Includes EMG's exclusive solderless wiring system for easy installation

Technical Specifications

Logo Color: Silver
Magnet Type: Ceramic
Resonant Frequency: 3.20 kHz
Output Voltage (Finger, Thumb): 2.00
Output Voltage (Thump): 4.50
Output Noise (60 Hz): -106 dBV
Output Impedance: 10 kOhm
Current (@9V): 80 µA
Battery Life: 3000 hours
Maximum Supply Voltage: 27 V DC

What's Included

• 1 EMG 35P Pickup, 3.5" x 1.5" Housing
• 1 25k Volume Pot
• 1 25k Tone Pot
• 1 Battery Bus
• 1 Stereo Output Jack
• 1 Pair of Mounting Screws
• 1 Pickup Cable
• 2 Connect Cables
• 1 Output Cable
• 1 Battery Cable

Disclaimer: The image above may not accurately depict the product and is for reference only. Some variations in appearance may occur.
