Fiberplex SFP-MC24XC-3131-2 SFP Optical Multimode 1.25 Gbps 1310nm Transceiver
Fiberplex SFP-MC24XC-3131-2 SFP Optical Multimode 1.25 Gbps 1310nm ...
Free Shipping
Fiberplex SFP-MC24XC-3131-2 SFP Optical Multimode 1.25 Gbps 1310nm Transceiver
The FiberPlex Technologies SFP-MC24XC-3131-2 Small Form Factor Pluggable (SFP) transceivers are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA). The SFP transceivers are high-performance , cost effective modules supporting a host of data rates and distances. They are RoHS compliant and lead-free. These optical modules are designed for digital data applications and are not recommended for digital video applications due to SMPTE encoding that may cause pathological signal errors.
Key Features
- Duplex LC connector
- Hot-pluggable SFP footprint
- RoHS compliant and Lead Free
- Metal enclosure for lower EMI
- Single +3.3V power supply
- Low power dissipation <800mW
- SFP MSA SFF-8074i Compliant
Technical Specifications
Voltage Range
Min - 3.13; Typ. - 3.3; Max - 3.47; Unit - VDC
Supply Current
250 mA
Depth
2.23 in
Height
0.47 in
Width
0.54 in
Product Weight
0.05 lbs
Operating Temperature (Maximum)
158 F
Operating Temperature (Minimum)
32 F
