Fiberplex TKIT-3GXC-M 3GSDI Video to Multimode Optical Conversion Transceiver Pair
Fiberplex TKIT-3GXC-M 3GSDI Video to Multimode Optical Conversion T...
Free Shipping
Fiberplex TKIT-3GXC-M 3GSDI Video to Multimode Optical Conversion Transceiver Pair
The FiberPlex Technologies `TKIT' bundles takes the incredible flexibility of the TD-6010 12.5 Gbps workbox and bundles it with a set of application specific SFP modules to create a simple, easy to order solution for your specific application. Includes AC Power Adapters.
Key Features
- SMPTE 424M, SMPTE 344M, SMPTE 292M and SMPTE 259M compliant
- Integrated Reclocker and Cable Driver
- Supports DVB-ASI at 270Mb/s
- Supports Audio in SDI stream
- Supports video pathological patterns for SD-SDI, HD-SDI and 3G-SDI
- Control via serial interface including: Input signal detection, Reclocker Rate & Lock, Voltage & Temperature Monitoring, Bypass Reclocker stage, Module Information
Technical Specifications
Storage Temperature (C)
-40 - 85C
OperatingTemperature (C)
0 - 50C
Interface
Full speed USB 2.0 compliant MicroB Device
Optical Modules
2 SFP+ MSA (SFF-8431, SFF-8432, SFF-8433) compliant slots, data rate 0 - 12.5 gigabits
