Condition: New
Focusrite Red 8Line 58-Input / 64-Output Thunderbolt 3 Audio Interface
Overview
The Red 8Line is a professional-grade, rackmount Thunderbolt 3 audio interface offering extensive analog, digital, and networked I/O in a single 1U solution. It combines ultra-high-quality conversion, remote-controlled mic pres, Dante network integration, and streamlined DAW switching for demanding studio, broadcast, and immersive audio environments.
Key Features
- 58 analog inputs / 64 outputs—delivering extremely flexible routing and integration
- 2 Red Evolution mic preamps with up to 63 dB gain, phantom power, high-pass filter, phase-reverse, and Air mode
- High-performance 24-bit/192 kHz A-D and D-A conversion: 119 dB A-weighted (A-D), 121 dB A-weighted (D-A)
- Dual Thunderbolt 3 ports for ultra-low-latency PC/Mac integration with daisy-chaining
- Dual Mini DigiLink ports for seamless Pro Tools | HD integration
- 32×32 Dante networked I/O with dual RJ-45 redundancy
- ADAT I/O (16-in/16-out at 48 kHz) and stereo S/PDIF I/O
- Independent L/R monitor outputs and dual headphone outputs
- Front-mounted dual Hi-Z instrument inputs
- Three LCD displays for precise metering of inputs/outputs, monitors, and headphones
- Full control via RedNet Control software and compatibility with the RedNet R1 remote
- Hitmaker Expansion plugin bundle and Focusrite plugin suite included
Technical Specifications
- Analog I/O: 2 mic pre (XLR), 2 Hi-Z instrument (¼″), 8 line in/out (DB25), 2 monitor outs (¼″), 2 headphone outs (¼″)
- Digital I/O: ADAT (2x TOSLINK), S/PDIF (1x RCA in/out)
- Clocking: Word Clock I/O and Loop Sync via BNC
- Host Connectivity: 2x Thunderbolt 3 (USB-C), 2x Mini DigiLink
- Network Connectivity: 2x RJ-45 (Dante)
- Sample Rates: 44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz
- Rack Spaces: 1U (19″ rackmount)
- Power Supply: Internal 100–240 VAC PSU
What’s Included
- 1x Focusrite Red 8Line interface unit
- 1x IEC power cable
- 1x Thunderbolt 3 and networking documentation
- RedNet Control software access
- Hitmaker Expansion and Focusrite plugin bundle downloads
- 3-year manufacturer’s warranty
