Hall Technologies CUSB3V1-AP50 USB 3.0 Javelin Active Optical Plenum Cable with Regulated Power, 50 Meters

They also work with USB 2.0 or 1.1 devices although this feature is only available for PCs running Windows and needs a driver installation. Driver installation is not required for extending purely USB 3.0 devices on any platform (PC, Mac, Linux).The cable is a light-weight hybrid of fiber and copper, and is plenum rated to ensure compliance with modern building codes. The small cable ends can be easily pulled through most conduit, and no additional power is required, making the CUSB3V1-AP* a true plug-and-play solution.

Key Features

• Data transfer rates of up to 5 Gigabits per second
• Offers fiber-optic noise immunity
• Plenum Rated
• Provides precise regulated 5v output power at the remote end @ up to 900 ma
• Supports all USB 3.0 devices on all platforms
• Thin and flexible with bend radius of 0.3 inch
• No additional power supply required

Technical Specifications

Input
Male USB 3.0 Type A
Output
Female USB 3.0 Type A
Available Lengths
15m (~50ft), 30m (~100ft), 50m (~164ft), 75m (~246ft) and 100m (~328ft)
USB Standards
USB 3.0 or USB 3.1 Gen 1
Bandwidth
5 Gbps max
Supply Voltage
Powered from USB 5v pin
Nominal: 5v (operating range: 4.7v~5.3v)
Damage will occur if 5v input > 6v
Supply Current
Nominal: 50 ma max (not including remote USB device load)
Load Ratings
15 meter: 5V 850 ma
30 meter: 5V 700 ma
50 meter: 5V 700 ma
75 meter: Must use power inserter built into the connector head, power insertion cable included.
100 meter: Must use power inserter built into the connector head, power insertion cable included.
Power Consumption
Nominal: 0.25 watts
Grade
Plenum CMP (UL)
Color
Black
Diameter
5 mm (0.2 inch)
Bend Radius
8mm (0.3 inch) minimum
Connector Pull Strength
10 Kg (22 lbs) maximum (never pull on the connector, use a pulling sock
Connector Housing Dimensions
USB A Male (Host side)
1.4 inch x 0.6 inch x 0.3 inch (35.6mm x 15.3mm x 7.6 mm)
Total length including USB and Strain relief: 2.3 inch (58.4mm)
USB A Female (device side)
1.8 inch x 0.6 inch x 0.3 inch (45.7mm x 15.3mm x 7.6 mm)
Total length including Strain relief: 2.2 inch (55.9mm)
Temperature/Humidity
Storage
-4 to +158 F (-20 to +70 C) / 5% to 90%, non-condensing
Operating
+32 to +122 F (0 to +50 C) / 10% to 85%, non-condensing
Regulatory EMI/EMC
CE, RoHS
CE, FCC Class A
