IC Realtime PS-DC16A08HD-4DK 8-Channel 16 Amp DC Power Supply

IC Realtime PS-DC16A08HD-4DK 8-Channel DC Power Supply

The IC Realtime PS-DC16A08HD-4DK is a high-performance 8-channel DC power supply designed to provide reliable and efficient power distribution for your surveillance system. With an input voltage range of AC 110-220V and an output of DC 12V at 16A (maximum), this power supply ensures consistent power delivery to up to 8 devices simultaneously. Its robust construction and efficient design make it an ideal choice for both residential and commercial security installations.

Featuring a compact form factor, the IC Realtime PS-DC16A08HD-4DK measures 8 inches in width, 9.8 inches in depth, and 2.3 inches in height, allowing for easy integration into various setups. The unit operates efficiently with an efficiency rating of ≥82%, ensuring minimal energy loss during operation. Additionally, it is equipped with PTZ fuses rated at 2000mA to protect connected devices from potential power surges or short circuits.

Designed to operate within a temperature range of 14°F to 104°F (-10°C to 40°C), the IC Realtime PS-DC16A08HD-4DK is built to withstand varying environmental conditions. Its lifespan of 10,000 hours ensures long-term reliability, making it a dependable component of your security infrastructure. The power supply comes in a sleek white and royal blue color scheme, weighing approximately 3.93 pounds, which facilitates easy handling and installation.

Key Features

• Supports up to 8 channels for simultaneous power distribution
• High efficiency rating of ≥82% for energy-saving operation
• Compact dimensions for versatile installation options
• Equipped with PTZ fuses rated at 2000mA for enhanced safety
• Operates within a wide temperature range, suitable for various environments
• Durable design with a lifespan of 10,000 hours
• Attractive white and royal blue color scheme

Technical Specifications

Model: IC Realtime PS-DC16A08HD-4DK
Input Voltage: AC 110-220V 4A 47-63Hz
Output: DC 12V 16A (MAX)
Max Channels: 8
Efficiency: ≥82%
Fuse Type: PTZ Fuse
Fuse Rating: 2000mA
Operating Temperature: 14°F-104°F (-10°C to 40°C)
Life: 10,000 hours
Load Regulation A: ±5%
Color: White and Royal Blue
Weight: 3.93 lb (1.785 kg)
Dimensions (W×D×H): 8” x 9.8” x 2.3” (205 mm x 250 mm x 60 mm)

What's Included

• IC Realtime PS-DC16A08HD-4DK 8-Channel DC Power Supply Unit
• Power Cord
• User Manual
