Audio-Technica ATM230 Hypercardioid Dynamic Instrument Microphone
The ATM230 hypercardioid instrument microphone brings a compact drum model to Audio-Technica’s popular Artist Series line. The mic’s proprietary capsule is designed to excel in high SPL applications, delivering full, well-rounded audio with an exceptional low-end. The hypercardioid polar pattern keeps the focus on the sound source, directionality that is aided by the mic’s low-profile design, which allows it to be placed in a wide variety of setups. All this makes the ATM230 ideally suited for miking toms, snare and other percussion instruments.
Key Features
- Hypercardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source
- Handles very high SPL at close range
- Big, warm low-frequency response with excellent attack
- Low-profile design permits versatile placement around drum kit
- Rugged, all-metal design and construction for years of trouble-free use
- Includes AT8665 drum mount and a soft protective pouch
Technical Specifications
ELEMENT
Dynamic
POLAR PATTERN
Hypercardioid
FREQUENCY RESPONSE
30-12,000 Hz
OPEN CIRCUIt'sENSITIVITY
-54 dB (1.9 mV) re 1V at 1 Pa
IMPEDANCE
600 ohms
WEIGHT
292 g (10.3 oz)
DIMENSIONS
82.5 mm (3.2") long,
38.0 mm (1.5") maximum diameter
OUTPUT CONNECTOR
Integral 3-pin XLRM-type
ACCESSORIES FURNISHED
AT8665 drum mount for 5/8"-27 threaded
adaptor; 5/8"-27 to 3/8"-16 threaded
adaptor; soft protective pouch
AUDIO-TECHNICA CASE STYLE
R2
