KanexPro HDSC92D-4KTX Input Extender for HDSC92D-4K Scaler
The KanexPro HDSC92D-4KTX is an HDMI over single Cat5e/6 Transmitter can send uncompressed audio/video and IP data over a single run of CAT5e/6/ cable at a distance up to 100 meters. The Receiver features pass-through of control through the built-in RS-232and IR ports and a bi-directional LAN connection which allows for integrators to pass data through the extender. The transmitter can be powered by the PoE 48V power which can be supplied by a POE injector or by the receiving device. This unit has been specifically designed to operate with the KanexPro HDSC92D-4K Scaler system or can be used as a stand-alone extender when combined with the KanexPro HDSC92D-4KRX receiver.
Key Features
- HDMI with 3D & 4K support, DVI 1.0compatible
- HDCP 2.2 and HDCP 1.xcompliant
- Supports resolutions up to 4K@50/60Hz (4:2:0, 8-bit)
- Supports CEC by pass
- Simultaneous transmission of uncompressed video, audio and data over a single 100m/328ft Cat.5e/6/7 cable at 1080p60and70m/230ft at 4K
- HDBaseT feature support: HD Video and Audio, 100BaseTEthernet, 48VPoH, and Control (bidirectional IR/RS-232pass-through)
- Supports standard 48V PoH from Receiver (PSE) to Transmitter (PD) (compatible Transmitters only)
Technical Specifications
Video Bandwidth
340Hz/10.2Gbps
Input Port
1xHDMI
Output Port
1xCat.5e/6/6a
Pass-through Ports
1xIR Extender <3.5mm>
1xIR Blaster <3.5mm> 1xRS-232 <9-pinD-sub> 1xLAN
Supported Resolutions
480i@60Hz - 4K@60Hz (4:2:0, 8-bit)
VGA@60Hz - WUXGA@60Hz (RB)
HDMI Cable Length
10m (1080p@60Hz, 12-bit)
5m (4K@60Hz, 4:4:4, 8-bit)
CAT5e/6 Cable Length
100m (1080p@60Hz, 12-bit)
70m (4K@60Hz, 4:2:0, 8-bit)
IR Frequency
30-50 kHz (30 - 60 kHz under ideal conditions)
Baud Rate
Up to115200bps
Power Supply
48VPoH
ESD Protection
Human Body Model
Ā±8kV (Air Discharge)
Ā±4kV (Contact Discharge)
Dimensions
128mmx25mmx108mm (WxHxD)
128mmx25mmx117m (WxHxD)
Weight
370g
Chassis Material
Metal
Silkscreen Color
Black
Operating Temperature
0Ā°C - 40Ā°C/32Ā°F -104Ā°F
Storage Temperature
-20Ā°C - 60Ā°C/-4Ā°F -140Ā°F
Relative Humidity
20 - 90% RH (Non-condensing)
Power Consumption
4.71W
