Kramer 3KHVE2R HDb3000 HDMI RF/IP Media Module Blade

Kramer | SKU: KRMR-3KHVE2R
$1,90000

Free Shipping

Estimated Shipping Widget will be displayed here!

Enjoy free standard shipping on all orders over $99. Please note that this offer excludes oversized, overweight, special orders, custom products, and items with minimal profitability. Most orders placed before 10:00am PST will most likely ship out the same day. We work hard to process and ship your items quickly so you can start enjoying them as soon as possible. Found a lower price? Contact us and we'll see if we can match it! Price match will only be applied to products sold and shipped by authorized retailers of the brand. No restocking fee will be charged when you opt for store credit. Exclusions apply.

Condition: New

Kramer 3KHVE2R HDb3000 HDMI RF/IP Media Module Blade

The Kramer 3KHVE2R delivers dual-channel HDMI input (up to 1080p) with embedded or analog audio, encoding it into MPEG-2 streams for simultaneous RF QAM/DVB-T/C modulation and network streaming. Designed for hot-swappable use in the HDb3000 chassis, it supports closed captioning and independent audio delay control.

Optimal for AV-over-IP headend setups in hospitality, enterprise, and broadcast, the module features front-panel LCD configuration and remote management via ZeeVee Maestro. It integrates seamlessly into a 3RU rack space with redundant cooling and flexible power options.

Key Features

  • 2 × HDMI inputs (up to 1080p) with embedded or analog audio support
  • Simultaneous RF (QAM/DVB-T/C) modulation and UDP/IP streaming
  • Dual-channel audio delay matching for synchronized playback
  • Closed-captioning support via HDMI input
  • Delivers up to 24 HD channels per chassis (2 per slot × 12 slots)
  • Hot-swappable, rack-optimized design with redundant fans
  • Configurable via front-panel LCD or network GUI
  • Chassis inverted, wide-range AC power supply (100-240 VAC, IEC C14)

Technical Specifications

  • Dimensions: 5″ × 0.85″ × 11″ (127 × 21 × 279 mm)
  • Weight: 1.10 lb (0.50 kg)
  • Operating Temperature: 32-113 °F (0-45 °C)
  • Power Input (Chassis): 100-240 VAC, 300 W, IEC C14
  • Cooling: Four hot-swappable N+1 fans, front inlet/rear exhaust
  • RF Output: QAM‑64/256 or DVB‑T/C, frequency range 54-864 MHz, output level 13-34 dBmV, MER >39 dB
  • IP Output: 10/100 Mb Ethernet, DHCP or static IP
  • Encoding: MPEG‑2, approx. 18 Mb/s per channel, latency 200-400 ms
  • Audio: HDMI-embedded digital plus analog L/R with adjustable delay
  • Closed Captioning: Supported via HDMI input

What’s Included

  • 3KHVE2R module with pre-loaded firmware
  • Access to ZeeVee Maestro control software
