The PT-102AN is a high-performance audio distribution amplifier for unbalanced stereo signals. The unit takes one stereo input and distributes the signal to two identical stereo outputs.
Key Features
- Level (Gain) Controls.
- S/N Ratio - 85dB.
- Ultra-Compact Pico TOOLS - 4 units can be rack mounted side-by-side in a 1U rack space with the recommended rack adapter.
Technical Specifications
INPUT
1 unbalanced stereo audio on a 3.5mm mini jack
OUTPUTS
2 unbalanced stereo audio on 3.5mm mini jacks
MAX. OUTPUT LEVEL
5Vpp
BANDWIDTH (-3DB)
>100kHz
S/N RATIO
85dB @1kHz
CONTROLS
Level: - 55dB to +20dB
COUPLING
AC
AUDIO THD + NOISE
0.01% @1kHz
AUDIO 2ND HARMONIC
0.004% @1kHz
POWER CONSUMPTION
12V DC, 20mA
INCLUDED ACCESSORIES
Power supply, mounting bracket
PRODUCT DIMENSION
6.22cm x 5.18cm x 2.44cm (2.45" x 2.04" x 0.96" ) W, D, H
PRODUCT WEIGHT
0.1kg (0.2lbs) approx.
