Kramer WP-20 4K UHD HDMI and VGA with Ethernet Bidirectional Active Wall Plate

The WP-20 is a 4K UHD, HDBaseT active wall plate auto switcher for HDMI, VGA and analog audio signals that supports resolutions up to 4K@60Hz (4:2:0) UHD. The device has EDID management, various control options and audio embedding. The unit is a fully-featured auto-switcher with the convenience and simplicity of a wall plate. The WP-20 is easy to configure, can be powered remotely over Ethernet (PoE) and is designed for any size room.

Key Features

• Max. Data Rate - 10.2Gbps (3.4Gbps per graphic channel)
• Max. Resolution - Up to 4K@60Hz (4:2:0) UHD and WUXGA
• HDTV Compatible
• HDCP Compliant - Works with sources that support HDCP repeater mode
• HDMI Support - Deep Color, x.v.Color and 3D
• Automatic Live Input Detection - Based on video clock presence
• Automatic Input Selection - Based on manual selection or last connected input
• Automatic Analog Audio Detection & Embedding
• I-EDIDPro Kramer Intelligent EDID Processing - Intelligent EDID handling & processing algorithm ensures Plug and Play operation for HDMI systems
• Kramer Equalization & re-Klocking Technology - Rebuilds the digital signal to travel longer distances
• Range - Up to 130m (430ft) at normal mode (2K), up to 100m at normal mode (4K); up to 180m (590ft) ultra mode (1080p @60Hz @24bpp) when using BC-HDKat6a cables
• Lockable EDID
• Flexible Control Options - Via Kramer Protocol 3000, Ethernet and embedded Web pages over RS-232
• Digital Audio Format Support
• Mounting Option - For wall mounting, use Kramer's OWB-2G

Technical Specifications

INPUTS
1 HDMI on an HDMI connector, 1 VGA on a 15-pin HD (F) connector, 1 unbalanced stereo audio on a 3.5mm mini jack.
OUTPUTS
1 HDBaseT on an RJ-45 connector, 1 unbalanced stereo audio on a 3.5mm mini jack.
PORTS
1 RS-232 3-pin terminal block, 1 Ethernet on an RJ-45 connector.
CONTROLS
Remote switches for input switching and volume control, reset switch.
STANDARDS
HDMI with Deep Color, x.v.Color and 3D; HDCP-works with sources that support HDCP repeater mode; HDBT certified.
MAXIMUM ANALOG AUDIO LEVEL
3.1Vpp.
THD
0.013%.
SNR
-70dB.
SUPPORTED WEB BROWSERS
Windows 7 and higher: Internet Explorer (32/64 bit) version 11, Firefox version 30, Chrome version 35; MAC: Chrome version 35, Firefox version 27, Safari version 7.
MAXIMUM TRANSMISSION DISTANCE
180m (590ft) up to 1080p @60Hz @24bpp in extended mode, 130m (430ft) up to 1080p @60Hz @36bpp in normal mode.
POWER CONSUMPTION
12V DC, 850mA.
OPERATING TEMPERATURE
0 to +40C (32 to 104F).
STORAGE TEMPERATURE
-40 to +70C (-40 to 158F).
HUMIDITY
10% to 90%, RHL non-condensing.
COOLING
Convection.
ENCLOSURE TYPE
Aluminium.
DIMENSIONS
2 gang USA 11.6 cm x 5.1cm x 11.4cm (4.57" x 2.01" x 4.49") W, D, H; 2 gang EU 15.1cm x 4.7cm x 8.6cm (5.94" x 1.85" x 3.39") W, D, H.
WEIGHT
0.23kg (0.51lbs) approx.
SHIPPING WEIGHT
0.51kg (1.12lbs) approx.
ENVIRONMENTAL REGULATORY COMPLIANCE
RoHs and WEEE.
VIBRATION
ISTA 1A in carton (International Safe Transit Association).
COMPLIANCE STANDARDS
CE.
INCLUDED ACCESSORIES
Power adapter.
OPTIONS
Faceplates: WP-20-BLNK(W) P/N 68-80371099, WP-20-BLNK(B) P/N 68-80371199.
WARRANTY
7 years parts and labor.
