Laird LDC-15NMF-PCTF Edison Power Distribution Splitter Cable
The Laird LDC-15NMF-PCTF is an Edison power distribution splitter designed to route power from a NEMA 5-15 Edison male plug to professional locking and standard output connectors. It is built for live events, audio systems, and lighting rigging where dependable power distribution is required.
This LDC-15NM series splitter supports feed thru power routing to allow daisy chaining of multiple boxes while maintaining uninterrupted power delivery. Premium cabling and Neutrik connectors are selected to support consistent performance in demanding production environments.
Ideal for touring rigs, stage power drops, and production racks, this splitter simplifies power management in compact setups. Its rugged aluminum enclosure and professional grade components support reliable operation in the field.
Key Features
- Power Distribution: Routes power from a NEMA 5-15 Edison male plug to mixed output connectors.
- Dual Output Design: Provides one Neutrik powerCON TRUE1 female output and one Edison female receptacle.
- Daisy Chain Support: Feed thru connectors enable chaining multiple power distribution boxes.
- Rugged Power Cable: Built using Laird PWR-12-3-TP rugged yet flexible power cable.
- Durable Enclosure: Rugged aluminum enclosure designed for professional field use.
Technical Specifications
- Input Connector: 1 Edison male plug.
- Output Connectors: 1 Neutrik powerCON TRUE1 female and 1 Edison female receptacle.
- Enclosure Dimensions: 4 x 2.04 x 1.24 in.
- Cable Type: SJOOW.
- Conductors: 3 x 12 AWG.
- Current Carrying Capacity: 25 A.
- Cable Outer Diameter: 0.42 to 0.47 in.
- Outer Jacket: Rubber CPE black.
- Cable Insulation: Rubber EPR.
- Neutrik Connector Amperage: 20 A.
- Neutrik Connector Rated Voltage: 250 VAC.
- Leviton Connector Amperage: 15 A.
- Leviton Connector Rated Voltage: 125 VAC.
- Leviton Contact Material: Solid brass.
