Panasonic PT-MZ14KLBU7 14000 Lumen LCD WUXGA Projector, Black
The Panasonic PT-MZ14KLBU7 is a high-performance 14,000-lumen LCD projector engineered to deliver brilliant, full brightness using a wide AC 100–240 V input. Designed for easy installation without the need for elaborate high-voltage setups, this projector also features Near Field Communications (NFC) that streamlines its configuration—even before power up. With a comprehensive lineup of optional lenses and pre-activated Geometry Pro upgrade kits, the system adapts to tight spaces and supports PC-based adjustments for versatile installation requirements.
Ideal for professional and commercial applications, the PT-MZ14KLBU7 combines energy-saving durability with a quiet operation and advanced connectivity—including USB, HDMI, SDI, and specialized network ports. The projector’s fully featured interface and multiple adjustment options ensure that it meets the demands of modern presentation and display environments while maintaining reliable performance.
Key Features
- Lighting and Performance: 14,000 lm LCD projector designed to be small, light, and quiet.
- Energy Efficiency: Long-life energy-saving design that minimizes maintenance issues.
- Projection Method: Front projection ensuring versatile setup options.
- Illumination: Uses a single laser lamp for bright, consistent output.
- Connectivity: Includes USB support for added functionality.
Technical Specifications
- Dimensions (W x H x D): Approx. 650 x 185 x 440 mm (about 25.6 x 7.3 x 17.3 inches)* (measurements vary slightly with the positioning of feet and protrusions).
- Lens: Optional – no lens included with this model.
- Resolution: WUXGA (1920 x 1200 pixels).
- Operating Environment: Temperature 0–45°C (32–113°F); humidity 10–80% (no condensation).
- Keystone Correction Range: Vertical: ±45° (with enhancements available using specific lenses); Horizontal: ±40°; combined correction up to 55° total.
- Screen Size (Diagonal): Ranges from 80 to 600 inches (varies with lens options such as ET-EMU100 or ET-EMT8004).
- Contrast Ratio: Up to 3,000,000:1 (Full On/Full Off) under designated dynamic modes.
- Power Supply: AC 100–240 V, 50/60 Hz.
- Light Source: Laser diode ensuring longevity and consistent light output.
- Connectivity and Terminals: Multiple ports including LAN (RJ-45), USB (Type A), HDMI, SDI (BNC), DIGITAL LINK (RJ-45 for HDBaseT), wired remote control (M3 connector), and serial/Multi Projector sync options.
- LCD Panel: Features a 25.4 mm (1.0 inch) diagonal transparent LCD panel (R/G/B) with an active-matrix drive method and a resolution of 2,304,000 pixels.
- Weight: Approximately 22.5 kg (49.6 lbs).
- Light Output: 14,000 lm ensuring clear and bright visuals.
- Power Consumption: Maximum around 800 W; On-mode consumption varies—720 W (AC 100–120 V) and 690 W (AC 200–240 V) in normal mode, with reduced consumption in quiet mode.
- Operation Noise: 35 dB in normal mode and 30 dB in quiet mode.
- Additional Features: NFC-enabled quick setup, adjustable lens shift (vertical and horizontal), and compatibility with multiple control softwares (e.g., PJLink, Art-Net, Geometry Manager Pro).
*Note: The dimensions in inches have been approximated for ease of reference.
