The LevelOne FSW-1650 switch provides an ideal solution for small businesses that demand a reliable network switch that provides a high bandwidth interface between file servers and workgroups, departments and offices. The FSW-1650 is a compact designed network switch. Users can place the switch on any desktop area or mount it in a 19-inch server rack or cabinet by using the included rack-mounting accessory kit.
Key Features
- Provides flexibility of 16 x 10/100BASE-TX ports
- 10/100Mbps, full/half-duplex, auto-negotiation, auto-MDI/MDIX
- Supports 8K MAC address auto-learning and auto-aging
- IEEE 802.3x Flow Control protects against lost packets for reliable data transmission
- Minimize carbon footprint with advanced energy efficient technology (IEEE 802.3az)
Technical Specifications
Standards
IEEE802.3(10BASE-T)
IEEE802.3u(100BASE-T)
IEEE802.3az Energy Efficient Ethernet
Buffer Memory
2MB
Port
Full Shielded - 16 port 10/100Mbps
Indicator
Power, LINK/ACT,100M
Transmission Method
Store- froward
Power Input
100-240V/AC
Power Consumption
6.6W
Backplane (Gbps)
3.2Gbps
MAC Address Table
8K
Operating Temperature
32 to 104F (0 to 40C)
Humidity
10 to 90% (non-condensing)
Packet Forwarding Rate
14880pps
Jumbo Frame (K)
2KB
Dimensions (WxDxH)
17.32 x 8.19 x 1.73" (440 x 208 x 44mm)
Approval and Compliance
EMI/EMS: CE/FCC
Item Includes
x1 FSW-1650
x1 Power Cord
x1 19" Rack Mount Kit
