Shure QLXD1 Digital Wireless Bodypack Transmitter - G50: 470 - 534 MHz

Shure QLXD1 Digital Wireless Bodypack Transmitter

The Shure QLXD1 Digital Wireless Bodypack Transmitter delivers exceptional 24-bit digital audio quality and advanced RF spectrum efficiency, making it the perfect choice for mid-size presentation spaces, music venues, and houses of worship. This bodypack transmitter provides a seamless wireless experience for both vocals and instruments, ensuring your performance always sounds its best.

With an impressive dynamic range of over 120 dB, you'll never need to worry about transmitter gain adjustments, and the AES 256-bit encryption guarantees secure transmission. The optional Shure SB900 lithium-ion rechargeable battery provides detailed runtime information and allows for convenient external charging. A backlit LCD screen and an easy-to-navigate menu system make this transmitter user-friendly, while the rugged metal construction ensures durability in any setting.

The QLXD1 also offers several selectable display modes to show group/channel, frequency, or battery runtime. With a 4-pin male mini connector (TA4M) and detachable 1/4 wave antenna, this bodypack transmitter is designed for maximum versatility and reliability, making it an essential addition to your audio gear.

Key Features

• Over 120 dB of dynamic range: no transmitter gain adjustments needed
• AES 256-bit encryption for secure transmission
• Optional Shure SB900 lithium-ion rechargeable battery with runtime reporting
• External charging contacts for docked charging
• Backlit LCD with easy-to-navigate menu and controls
• Selectable display mode showing group/channel, frequency, or battery runtime
• 4-pin male mini connector (TA4M)
• Rugged metal construction
• Detachable 1/4 wave antenna
• Frequency and power lockout

Specifications

• Mic Offset Range: 0 to 21 dB (in 3 dB steps)
• Battery Type: Shure SB900 Rechargeable Li-Ion or AA batteries 1.5 V
• Battery Runtime @ 10 mW: Shure SB900: up to 10 hours, Alkaline: up to 9 hours
• Dimensions: 86 mm × 65 mm × 23 mm (3.38 in. × 2.57 in. × 0.92 in.) H × W × D
• Weight: 138 g (4.9 oz.), without batteries
• Housing: Cast aluminum
• Audio Input Connector: 4-pin male mini connector (TA4M)
• Configuration: Unbalanced
• Impedance: 1 M ohm
• Maximum Input Level: 1 kHz at 1% THD: 8.5 dBV (7.5 Vpp)
• Preamplifier Equivalent Input Noise (EIN): System Gain Setting >= +20: -120 dBV, A-weighted, typical
• RF Output Connector: SMA
• Antenna Type: 1/4 wave
• Impedance: 50 ohm
• Occupied Bandwidth: <200 kHz
• Modulation Type: Shure proprietary digital
• Power: 1 mW or 10 mW (See Frequency Range and Output Power table, varies by region)

Installation / Use Cases

• Use as a digital wireless bodypack transmitter for compatible Shure QLX-D Digital Wireless systems.
• Suitable for mid-size presentation spaces, music venues, houses of worship, live events, and professional wireless audio setups.
• Use with compatible lavalier, headset, or instrument microphone setups using the TA4M input connection.
• Use 24-bit digital audio quality for clear wireless sound.
• Use AES 256-bit encryption for secure wireless transmission.
• Use the wide dynamic range to avoid manual transmitter gain adjustments.
• Use the backlit LCD and selectable display modes to view group/channel, frequency, or battery runtime.
• Use the external charging contacts with compatible docked charging accessories.
• Use the detachable 1/4 wave antenna and belt clip for bodypack wireless operation.

Package Contents

• Shure QLXD1 Digital Wireless Bodypack Transmitter
• 1/4 wave antenna
• Belt clip
• User guide
• Warranty card
