AtlasIED ECM-20 20A AC Power Conditioner and Spike Suppressor

AtlasIED ECM-20 20A AC Power Conditioner and Spike Suppressor

The AtlasIED ECM-20 is a robust 20A AC Power Conditioner and Spike Suppressor engineered to protect sensitive AV and electronic equipment. Designed for standalone use or integration with an ECS control system, the ECM-20 delivers comprehensive surge protection, noise filtering, and voltage monitoring. This reliable power distribution unit supports remote activation from up to 1000 feet away, making it ideal for large-scale installations or control-sensitive environments.

Engineered to fit conveniently within the AtlasIED ECM-RACEWY6 housing, the ECM-20 is built to handle high-demand power loads while maintaining a compact profile. It includes a clamping suppression system for voltage spikes, Extreme Voltage Shutdown (EVS) technology for unsafe conditions, and RFI/EMI filtering to prevent interference. Additional features such as a manual/auto switch, AC presence and activity indicators make the ECM-20 a high-performance solution for any critical power application.

Key Features

• 20A current rating with 2 AC outlets
• Manual/Auto On/Off Switch
• Incoming AC Present and Active LEDs
• Clamping Spike & Surge Suppression
• Remote Activation Compatible (up to 1000 feet)
• RFI and EMI Noise Filtering

Technical Specifications

• Current Rating: 20 Amps
• Power Requirement: 120V 60Hz
• Operating Voltage: 102–132VAC
• Minimum Spike Clamping Voltage: 460 VRMS @ 3000A
• Maximum Spike Clamping Voltage: 6000V
• Power Consumption: 0.5 Watts
• Certified Safety Listings: MET (UL 1449)
• Warranty Period: 12 months from date of purchase
