Mogami Gold Pedal SLP 18" Super Low Profile Patch Cable

Mogami Gold Pedal SLP 18-Inch Super Low Profile Pedalboard Patch Cable

The Mogami Gold Pedal SLP 18-inch patch cable is built for guitarists with large, multi-row, or unconventionally arranged pedalboards where effects units are spaced well apart or mounted on different tiers. Using Mogami's industry-standard W2319 instrument cable with an oxygen-free copper core and Minicake 90-degree low-silhouette connectors, it bridges longer inter-pedal runs without sacrificing the silent background and signal transparency that define the Gold series.

For players seeking the best 18-inch patch cable for a large pedalboard or professional live performance rig, the SLP 18-inch handles the routing challenges that shorter cables cannot - connecting pedals across rows, linking isolated power supply positions, or spanning the gap between a wah at the front of a board and a delay unit at the rear. Despite the longer run, the W2319's low-capacitance construction (155 pF/m) preserves high-frequency detail and prevents the treble rolloff that afflicts high-capacitance cables over even moderate distances.

The carbon-impregnated PVC sub-shield is especially relevant at longer cable lengths, where microphonic noise accumulates proportionally with cable mass. This conductive layer drains vibration-induced voltage before it reaches the signal conductor, and Mogami's ultra high-density spiral shield provides a complete electromagnetic barrier against stage lighting dimmers, wireless transmitters, and power supply noise - the interference sources most likely to affect longer cable runs in complex live rigs.

Key Features - Mogami Gold Pedal SLP 18-Inch Low Profile Patch Cable

• 18-Inch Length for Large Pedalboard Layouts: Spans multi-row or widely spaced pedal arrangements that 5- and 10-inch cables cannot reach, without resorting to generic bulk cable assemblies.
• Low Capacitance W2319 Construction: At 155 pF/m, the W2319 cable limits high-frequency signal loss over longer runs, preserving pick attack, harmonic content, and top-end clarity across the full pedal chain.
• Minicake 90-Degree Low-Silhouette Plugs: Compact right-angle connectors keep even longer cables flat against the board surface, preventing the cable lift and jack stress that standard RA plugs cause at this length.
• Carbon PVC Sub-Shield for Microphonic Noise Rejection: Drains vibration-induced noise along the entire cable run, which becomes proportionally more important as cable length increases in high-traffic live environments.
• Lifetime Warranty: Mogami's lifetime guarantee covers the full cable assembly, reflecting the professional build quality that touring guitarists and recording engineers rely on.

Technical Specifications - W2319 Cable

• Cable Series: Mogami Gold Pedal SLP
• Base Cable: Mogami W2319
• Length: 18 inches
• Connector Type: Minicake 90-Degree (Right Angle to Right Angle)
• Conductor: 12/0.18TA, 0.305mm² (#23 AWG), Oxygen-Free Copper
• Insulation Material: PE (Polyethylene), Clear
• Sub-Shield: Conductive PVC (Carbon PVC), 1.8mm O.D.
• Main Shield: Served Shield, Approx. 38/0.16TA
• Jacket: PVC, Black, 5.0mm O.D. (0.197")
• Capacitance: 155 pF/m (47.3 pF/ft) at 1kHz
• DC Resistance (Inner Conductor): 0.064 ohm/m (0.020 ohm/ft)
• DC Resistance (Shield): 0.026 ohm/m (0.0079 ohm/ft)
• Inductance: 0.3 uH/m (0.092 uH/ft)
• Electrostatic Noise: 0.13 mV Max.
• Electromagnetic Noise at 10kHz: 0.07 mV Max.
• Microphonics: 0.3 mV Max.
• Voltage Breakdown: DC 500V / 15 sec.
• Insulation Resistance: 100,000 MOhm x m Min. at DC 500V
• Flex Life: 11,000 cycles
• Operating Temperature: -4 degrees F to +140 degrees F (-20 degrees C to +60 degrees C)
• Warranty: Lifetime
