MuxLab 500767-RX-MM 3G-SDI/ST2110 Over IP Uncompressed Gateway Converter Receiver, MMF

The 3G-SDI/ST2110 over IP Uncompressed Gateway Converter allows HD-SDI and 3G-SDI equipment to be extended up to 100ft (30m) via UTP Cat 5e/6 cable or up to 1300ft (400m) via duplex multimode OM4 fiber with LC connectors, at up to 1080p resolution @ 60Hz uncompressed, in a point-to-point configuration. Point-to-multipoint and multipoint-to-multipoint configurations are also possible by connecting several units to a 10G Ethernet network. The unit provides a 1G Ethernet Switch port to connect additional network devices, and an RS232 port for remote control of end devices.

Key Features

• Transmit Uncompressed SDI video up to 3G-SDI (1080p @ 60Hz) over a 10G Ethernet network
• Supports the SMPTE ST-2110 protocol
• Extend up to 100ft (30m) over Cat5e/6, or 1300ft (400m) over OM4 fiber
• Supports 100’s of Transmitters & Receivers depending on network bandwidth
• Supports point-to-point, point-to-multipoint and multipoint-to-multipoint applications
• Supports a 1G Switch port for additional network devices
• Supports RS232 for remote control of end devices
• Managed via its Web interface and RestAPI
