Description
AVPro Edge AC-EXO-X-PLUS-KIT 48Gbps Fiber Optic HDMI Extender Kit
The AVPro Edge AC-EXO-X-PLUS-KIT is a 48 Gbps fiber optic extender kit designed for uncompressed HDMI 2.1 signal extension in professional AV installations. It supports Full 8K Ultra HD video with near-zero latency and long-distance transport over multimode fiber. Built for high-performance commercial environments, it consolidates audio, video, control, and networking into a streamlined fiber-based workflow.
This HDMI over fiber solution supports up to 8K/60 Hz 4:4:4 and 4K/120 Hz video, with compatibility for Dolby Vision, HDR10, HDR10+, and HLG. Advanced integration features include USB 2.0 KVM extension, 1 Gbps Ethernet extension, and HDMI ARC-eARC audio extraction options for modern AV system design. EDID management, HDCP support, and transmitter test pattern generation help simplify configuration and validation.
With immunity to electromagnetic interference, the AC-EXO-X-PLUS-KIT is ideal for demanding commercial deployments where signal integrity and reliability matter. It extends up to 300 meters over OM4 fiber and supports bidirectional IR and RS-232 control for flexible integration. Precision downscaling enables continued use of legacy 1080p displays while maintaining 8K and 4K HDR source workflows.
Key Features
- 48 Gbps HDMI 2.1 Extension: Uncompressed Full 8K Ultra HD transport over fiber.
- Near-Zero Latency: Less than 8 microseconds latency.
- Long-Distance Fiber Support: Up to 300 m over OM4 multimode fiber.
- USB 2.0 KVM Extension: Extends USB 2.0 with KVM functionality for peripherals.
- 1 Gbps Ethernet Extension: RJ45 port provides LAN extension for displays or devices.
- ARC and eARC Audio Support: Enables high-bitrate audio return with improved sync and control.
- Control Integration: Configurable bi-directional IR and RS-232 control support.
- Downscaling Capability: Scales 8K and 4K including HDR to 1080p.
Technical Specifications
- Video Resolutions: Up to 8K/60 Hz 4:4:4, 8K/30 Hz 4:4:4, 4K/120 Hz
- Bandwidth: 48 Gbps (FRL6)
- HDR Formats: Dolby Vision, HDR10, HDR10+, HLG
- Chroma Subsampling: 4:4:4, 4:2:2, 4:2:0
- Color Bit Depth: Up to 16-bit
- Downscaling: 8K / 4K to 1080p
- HDCP: HDCP 2.3 and earlier
- Fiber Type: Multimode OM3
- Fiber Connector: Simplex LC (Lucent Connector)
- Distance: OM2 up to 40 m; OM3 up to 200 m; OM4 up to 300 m
- USB Extension: USB 2.0; (1) USB Type-C (Transmitter); (4) USB Type-A (Receiver)
- Ethernet Extension: 1 Gbps; RJ45
- Audio Extracted Digital: TOSLINK
- Power Consumption: 12 W Maximum
- Power Supply: Input: 12 VDC/3a Power Supply; Output: 12v 3a
- Operating Temperature: 23 to 125 F (-5 to 51 C)
- Humidity Range: 5% to 90% RH (No Condensation)
- Warranty: 10 Years
