Maxhub C8630 86-Inch 4K Touch Display
More finance options:
Estimated Shipping Widget will be displayed here!
Orders placed between Monday - Friday before
1:00 PM PST will most likely ship out the same day. We work hard to process and ship your items quickly so you can start enjoying them as soon as possible.
Found a lower price? Contact us and we'll see if we can match it! Price match will only be applied to products sold and shipped by authorized retailers of the brand.
No restocking fee will be charged when you opt for store credit. Exclusions apply.
Condition: New
Description
MAXHUB V6 Classic Series Interactive Flat Panel C8630 86-Inch 4K Touch Display
The MAXHUB V6 Classic Series C8630 is an 86-inch interactive flat panel designed for professional meeting rooms, collaboration spaces, and presentation environments. It combines a high-resolution 4K display with integrated collaboration tools to support clear communication and efficient teamwork.
This interactive display supports wireless screen sharing, touch-based whiteboarding, and video conferencing with a built-in camera, microphone array, and speakers. With broad operating system compatibility and professional connectivity options, the C8630 is suited for corporate meeting rooms, boardrooms, and hybrid collaboration workflows.
Key Features
- 86-inch 4K UHD interactive flat panel with 16:9 aspect ratio
- 20-point IR touch system with high accuracy and fast response
- Wireless screen sharing and smart whiteboard functionality
- Built-in 48MP camera with auto frame and speaker tracking
- Integrated far-field microphone array with up to 8 m pickup range
- Built-in 2.1 channel speaker system for clear audio playback
- OPS slot support for optional PC module integration
Technical Specifications
Model
C8630
Diagonal Size
86 inch
Backlight
Direct-lit LED
Panel Technology
VA
Resolution
3840 x 2160
Refresh Rate
60 Hz
Response Time
8 ms
Brightness (typ)
350 cd/m²
Contrast Ratio
4000:1
Viewing Angle
178° / 178°
Color Gamut (typ)
90% NTSC
Product Dimensions (W x H x D)
77.05 x 45.67 x 3.94 inch
Shipping Dimensions (W x H x D)
83.07 x 50.51 x 6.86 inch
Net Weight
131.73 lbs
Gross Weight
169.76 lbs
Power Supply
AC 100-240 V, 50/60 Hz
Max Power Consumption
400 W
Standby Power
≤0.5 W
Touch Technology
IR Touch
Max Touch Points
20
Accuracy
±1 mm
Object Recognition Range
≥2 mm
Built-in Camera
Single camera, 48 MP
Speaker Output Power
2.1 channel, 2 x 10 W + 20 W
Microphone Array
8x far-field microphones, up to 8 m range
Operating Temperature
0°C to 40°C
Operating Humidity
10% to 90%
What’s in the Box
MAXHUB V6 Classic Series C8630 Interactive Flat Panel
Power Cord
Wi-Fi Adapter
Passive Stylus x2
Wall Mount
USB Type-C Cable (1.8 m)
