PreSonus AIR XD 12 1 x 12-Inch 2-Way Active Extended Definition Loudspeaker

The PreSonus AIR XD 12 is designed for professionals who demand powerful, full-range sound and clarity in any live situation. With its custom 12-inch woofer featuring a 2.56-inch voice coil, the speaker delivers tight, dynamic low frequencies down to around 48-Hz, providing rich bass even without a subwoofer. The 1.35-inch high-frequency compression driver equipped with a PEEK diaphragm ensures high-end detail, excellent response under load, and minimal distortion at high output. Together they are driven by a class-D amplifier capable of 1,500 Watts total output, letting you achieve up to 132 dB SPL with headroom to spare. This setup makes the AIR XD 12 an outstanding choice for mobile gigs, clubs, events, or installations where punch and fidelity both matter.

Versatility is built in: onboard DSP offers presets, ±10 dB EQ adjustment, and performance/venue tuning, all accessible through a full-color 2.6-inch LCD screen. Bluetooth V5.0 with TWS Bridge Mode allows for wireless stereo pairing, and the signal routing is flexible thanks to a 3-channel mixer with multiple inputs: combo mic/line connectors, aux stereo input, and Bluetooth source. Control features such as gain, volume, hi/lo EQ let you tailor your sound instantly.

Durability and deployment flexibility go hand in hand. The rugged H-PP molded cabinet, steel grille, dual handles (top and side), and multiple fly/suspension points (M10) make it road-ready and suitable for flying, pole mounting, or using as a wedge monitor. Dual-position pole socket gives you options for alignment (0° or a slight tilt of 7.5°), while the protection features like output limiting ensure reliability under real-world conditions.

Key Features

• Powerful 1,500 W Class-D amplifier system (LF + HF) delivering up to 132 dB SPL peak output
• Custom 12-inch woofer with enlarged 2.56-inch voice coil for strong low-end response
• 1.35-inch HF compression driver with PEEK diaphragm for crisp, resilient highs
• Onboard DSP with multiple performance presets, ±10 dB hi/lo EQ, and full-color LCD screen for control
• Wireless convenience via Bluetooth V5.0 + TWS Bridge Mode for stereo pairing
• Flexible mixing: 2 combo XLR/TRS mic/line inputs, aux input, and Bluetooth input
• Rugged build: molded H-PP cabinet, steel grille, handles, suspension/fly points, dual-position pole socket

Technical Specifications

Electronics:
Auxiliary Input: 1/8 in (3.5 mm) Stereo
Bluetooth: Bluetooth V5.0
Channels: Three
Connectivity: Bluetooth
Inputs: Four - (2 x XLR/TRS Mic/Line Combo, 1 x 1/8-inch TRS Stereo, Bluetooth Stereo)
Line Out: One - 1 x XLR Mix Out
Power Consumption: 3.3 A (230 V-50 Hz), 6.6 A (120 V)
Voltage Requirements: 100-240 VAC, 50-60 Hz

General:
Amplifier Type: Class-D
Color: Black
Product Name: AIR XD 12 2-Way Active Sound-Reinforcement Loudspeaker
Series: AIR

Hardware:
Audio Controls: Gain, Volume, Hi/Lo EQ
Cabinet Material: H-PP Molded
Cooling: Passive radiator
Grille Material: 1.2 mm Steel
HF Power: 468 W
HF Transducers: 1.35-inch Compression Driver
Handle: 1 Top, 1 Side
LF Power: 1,060 W
LF Transducers: 12-inch (2.56-inch Voice Coil)
Pole Socket: Dual Position (0°, 7.5°)

Inputs:
Line Input Connection Type: XLR/TRS Mic/Line Combo
Line Inputs Impedance: 30 kΩ
Line Inputs Maximum Level: +14 dBu
Microphone Preamp Input Impedance: 30 kΩ

Measurements:
Product Depth: 13.8 in
Product Height: 24.4 in
Product Height/Length: 24.4 in
Product Weight: 43.3 lbs
Product Width: 14.2 in

Miscellaneous:
DSP Features: Speaker modes, Location, Bass, Treble
Power Cable: IEC
Protections: Output limiter
Suspension: M10 Suspension Points; Flypoints: 2 Top, 1 Back

Output:
Line Outputs Connection Type: XLR Male, Balanced

Performance:
Peak SPL: 132 dB
Total Power Output: 1,500 Watts

Speakers:
Coverage Pattern: 90° (Horizontal) x 60° (Vertical)
Crossover Frequency: 1.6 kHz
Speaker Type: Active 2-Way
Total Impedance: NA

What’s Included

• PreSonus AIR XD 12 2-Way Active Extended-Definition Loudspeaker
• IEC Power Cable
• User Manual
• Warranty Information
