Yamaha DXR10 mk3 2-Way 10-Inch 2000W Powered Loudpeaker

Yamaha DXR10 mk3 2-Way 10-Inch 2000W Powered Loudpeaker

The Yamaha DXR10 mk3 Powered Loudspeaker is a compact yet powerful solution designed for professional audio applications requiring exceptional clarity, precision, and output. As the most portable model in the DXR mk3 series, it delivers an impressive 132 dB SPL while maintaining a lightweight and versatile form factor. Ideal for live sound reinforcement, stage monitoring, and portable PA systems, the DXR10 mk3 provides reliable performance across a wide range of environments.

Equipped with a newly developed 2000W Class-D amplifier, the DXR10 mk3 ensures high-efficiency power delivery and consistent sonic performance. Its 2-way, bi-amped design features a 10" low-frequency driver and a 1.75" high-frequency compression driver, both engineered for durability and accurate sound reproduction. Advanced FIR-X™ tuning combines FIR filtering and corrective EQ to minimize phase distortion, while Drive Motion Calibration™ enhances low-frequency response for tighter, more linear bass performance.

Designed for modern workflows, the DXR10 mk3 includes advanced DSP processing and flexible control options. Users can optimize performance using tailored DSP modes such as FOH/MAIN and MONITOR, with AUTO V/H POSITION functionality that automatically adjusts settings based on speaker orientation. Remote control via the D-Remote app (iOS and Android) allows for convenient adjustments, while Bluetooth® streaming capability adds further versatility. Built with a rugged yet lightweight ABS enclosure, the DXR10 mk3 is engineered for durability, portability, and professional-grade sound in any application.

Key Features

• Compact 2-way, bi-amped powered loudspeaker design
• 10" low-frequency driver and 1.75" high-frequency driver
• Powerful 2000W Class-D amplifier for high output performance
• Maximum SPL of 132 dB for demanding audio environments
• FIR-X™ tuning for phase-accurate sound and clarity
• Drive Motion Calibration™ for improved low-frequency response
• Advanced DSP modes including FOH/MAIN and MONITOR
• AUTO V/H POSITION for automatic optimization based on placement
• Bluetooth® audio streaming capability
• Remote control via D-Remote app (iOS and Android)
• Intelligent feedback suppressor to eliminate unwanted feedback
• Lightweight ABS enclosure with optimized port design
• Dual-angle pole mount (0° or -7° tilt) for flexible setup
• Rigging points for installation using eye bolts
• Optional U-bracket and protective cover available

Technical Specifications

Powered: Yes
Power Configuration: Single Amp
LF Driver Size: 10" Woofer
HF Driver Size: 1.75"
Total Power: 2000W Class D
Inputs: 2 x XLR-1/4" Combo
Outputs: 2 x XLR
Bluetooth: Yes
Frequency Range: 53 Hz – 20 kHz
Maximum Peak SPL: 132 dB
Signal Processing: DSP
Enclosure Material: ABS
Power Source: Standard IEC AC Cable
Manufacturer Part Number: DXR10MKIII
