Yamaha DXR12 mk3 2-Way 12-Inch 2000W Powered Loudspeaker

Yamaha DXR12 mk3 2-Way 12-Inch 2000W Powered Loudspeaker

The Yamaha DXR12 mk3 Powered Loudspeaker delivers an exceptional balance of power, clarity, and portability, making it an ideal solution for professional sound reinforcement applications. Designed as a versatile workhorse, it excels in front-of-house systems, stage monitoring, and side fill applications. With an impressive maximum SPL of 134 dB, the DXR12 mk3 provides the output and precision required for demanding live performances and events.

At the core of the DXR12 mk3 is a newly developed 2000W Class-D amplifier driving a 2-way, bi-amped system featuring a 12" low-frequency driver and a 1.75" high-frequency compression driver. This combination delivers powerful low-end response, detailed mids, and crisp highs. Advanced FIR-X™ tuning integrates FIR filtering and corrective EQ to reduce phase distortion, while Drive Motion Calibration™ ensures tight, controlled bass by optimizing low-frequency driver performance.

Engineered for flexibility and ease of use, the DXR12 mk3 incorporates advanced DSP processing with multiple operating modes, including FOH/MAIN and MONITOR, enhanced by AUTO V/H POSITION for automatic optimization based on speaker orientation. Users can control settings remotely via the D-Remote app on iOS or Android devices, while built-in Bluetooth® streaming adds convenience for modern audio workflows. Housed in a rugged yet lightweight ABS enclosure, the DXR12 mk3 is built to perform reliably in both portable and installed applications.

Key Features

• 2-way, bi-amped powered loudspeaker for professional sound reinforcement
• 12" low-frequency driver and 1.75" high-frequency driver
• High-performance 2000W Class-D amplifier
• Maximum SPL of 134 dB for powerful output
• FIR-X™ tuning for precise phase alignment and clarity
• Drive Motion Calibration™ for improved low-frequency accuracy
• Advanced DSP modes including FOH/MAIN and MONITOR
• AUTO V/H POSITION for automatic optimization based on placement
• Bluetooth® audio streaming capability
• Remote control via D-Remote app (iOS and Android)
• Intelligent feedback suppression for clean sound
• Durable and lightweight ABS enclosure
• Dual-angle pole mount (0° or -7° tilt) for flexible positioning
• Rigging points for installation using eye bolts
• Optional U-bracket and protective cover available

Technical Specifications

Powered: Yes
Power Configuration: Single Amp
LF Driver Size: 12" Woofer
HF Driver Size: 1.75"
Total Power: 2000W Class D
Inputs: 2 x XLR-1/4" Combo
Outputs: 2 x XLR
Bluetooth: Yes
Frequency Range: 53 Hz – 20 kHz
Maximum Peak SPL: 134 dB
Signal Processing: DSP
Enclosure Material: ABS
Power Source: Standard IEC AC Cable
Manufacturer Part Number: DXR12MKIII
