JBL CONTROL 31-WH Two Way High Output Indoor Outdoor Monitor Speaker White

JBL CONTROL 31-WH | Two Way High Output Indoor Outdoor Monitor Speaker White

The JBL CONTROL 31-WH is a state-of-the-art two-way high-output monitor speaker, designed for both indoor and outdoor use. Its reputation for delivering high-fidelity audio performance, extended bandwidth, and superior coverage makes it a standout choice for audiophiles and professional sound engineers alike. Utilizing advanced high-power components and sophisticated design, this speaker ensures unwavering performance even under long-term, high-power working conditions. The meticulous craftsmanship featuring a woven fiberglass cone low-frequency driver and a high-temperature polymer diaphragm compression driver ensures a clean, powerful audio experience regardless of the environment.

Optimized for both clarity and durability, the Control 31’s low-frequency driver features a durable woven fiberglass cone and pure butyl rubber surround, providing excellent weather resistance. Complemented by a high-temperature fiberglass voice coil former, the low-frequency driver not only ensures high sensitivity and output but also maintains stable performance over time. Furthermore, the speaker includes the patented InvisiBall mounting hardware, ensuring an easy and secure installation process. With an IP-55 rating for water and dust resistance, the Control 31 is designed to withstand the elements, making it an excellent choice for outdoor events and installations.

Key Features

• 250 mm (10 in) woven fiberglass cone LF driver with 52 mm (2 in) voice coil
• High-output 2414H-C compression driver with 25 mm (1 in) exit
• 250 Watt capability (8Ω thru setting), plus 150 Watt transformer for 70V or 100V distributed lines
• Extended bandwidth with smooth frequency response
• WeatherMax multi-layer grille for enhanced weather resistance
• 110° x 110° symmetrical coverage
• Includes InvisiBall mounting hardware and ten 6 mm attachment points
• Sealed input panel cover and screw-down input terminals

Specifications

• Frequency Range (-10 dB): 33Hz – 19kHz
• Frequency Response (±3 dB): 42Hz – 14kHz
• Power Ratings: 250 W (1000 W peak), 2 hrs; 200 W (800 W peak), 100 hrs
• Maximum SPL @ 1m: 116 dB continuous (123 dB peak)
• Nominal Sensitivity: 92 dB
• Coverage Angle: 110° x 110°
• Directivity Factor (Q): 5.7, averaged 500 Hz to 10 kHz
• Directivity Index (DI): 7.3 dB, averaged 500 Hz to 10 kHz
• Nominal Impedance: 8 ohms
• Crossover Type: 2nd order low-pass, 2nd order high-pass, plus conjugate shaping circuitry
• Transformer Taps: 70V: 150W, 75W, 38W, 19W; 100V: 150W, 75W, 38W
• Insertion Loss: <0.65 dB at any tap setting
• Thru Setting: 8Ω nominal
• Recommended High-Pass: Protective 40 Hz high-pass (24 dB/oct) for any transformer tap and for 8Ω operation
• Low Frequency: 250 mm (10 in) woven-fiberglass cone with pure butyl rubber surround
• High Frequency: JBL 2414H-C compression driver with 25 mm (1 in) diaphragm
• Enclosure Material: High impact Polystyrene (HIPS) with 10% glass fill
• Grille: Zinc-plated and thermoset-composite coated steel
• Dimensions: 593 x 372 x 345 mm (23.3 x 14.6 x 13.5 in)
• Weight (each): 18.8 kg (41.5 lb)
• Shipping Weight (each): 22.0 kg (48.5 lb)

Package Contents

• 1 pc MTC-PC2 input panel cover
• InvisiBall wall-mounting system
• 6 mm x 305 mm InvisiBall hex wrench
• Optional Marine-Kit Grille in black or white
• Optional Ceiling-Mount Adapter
• Optional U-Bracket
