Potter EVD-R Electronic Vibration Detector Remote Pickup
The EVD-R remote pickup detects attack vibrations with the same vibration sensing components as the internal pickup on the EVD-M controller. The EVD-R amplifies and transmits these vibrations to the EVD-M controller.
A cover tamper and a back tamper protect the EVD-R from cover removal or prying. If either of these tampers activate or the tamper from the safe contact interface activates, the EVD-R will signal a tamper condition to the EVD-M. During a tamper condition, the EVD-R network is fully capable of signaling alarm conditions to the EVD-M controller. If more than five EVD-R remote pickups simultaneously signal tamper to the EVD-M controller, the EVD-M will signal an alarm.
The EVD-R contains a magnetically activated test switch that permits testing of each EVD-R in the remote pickup network. The EVD-R provides terminals for the connection of dry contacts from any Underwriters Laboratories listed safe contact.
Key Features
- Detects all common threats to safes and vaults
- Reliable, sensitive piezo sensor technology
- Low cost, standalone system
Technical Specifications
Depth
1.2ā
Depth (mm)
30.48
Height
5.1ā
Height (mm)
129.54
Weight (Approximate)
9.92 oz
Width
3.3ā
Width (mm)
82.804
Product Information
Installation Type
Commercial
Miscellaneous
Compatibility
Potter EVD-2 Electronic Vibration Detector System
