Prism Sound 8C-AES AES I/O Module for Dream ADA8XR
The 8C-AES AES3 I/O Module type PREV039/6/1 provides eight channels of digital audio input and output for the ADA-8XR on four AES3 carriers in each direction. The input and output sections of the module are completely independent – that is, they can be assigned to different Paths with different sample rates, Sync Sources and other options. The AES3 I/O module can be thought of as two modules in one – one input module and one output module.
The module can accommodate extended sample rates (up to 192kHz) in Split96 (two-wire) or high-speed (one-wire) modes, and can output consumer or professional Channel Status. Inputs and outputs may be jumpered to comply with either AES3 or S/PDIF carrier voltage levels and impedances.
Technical Specifications
Group delay (AES3 to output)
34/fs
Connection
Transformer-coupled female DB25 connector
AES3 mode: I/O impedance
110 Ohm;
Output carrier amplitude (loaded)
3.2Vp-p
S/PDIF mode: I/O impedance
75 Ohm;
Output carrier amplitude (loaded)
0.5Vp-p
Output channel status
Professional or consumer
Input jitter tolerance
15UIp-p below 200Hz;
0.5UIp-p above 8kHz (1UI=163ns @ 48kHz)
Wordlength
16, 20 or 24-bit
