Pure Resonance Audio MX9 9-Channel Rack Mount Mixer
Pure Resonance Audio MX9 9-Channel Rack Mount Mixer
Free Shipping
Pure Resonance Audio MX9 9-Channel Rack Mount Mixer with Bluetooth and Effects
The Pure Resonance Audio MX9 redefines rack mount audio mixing with versatile control of 9 mixing channels in a space-saving 3U chassis, perfect for professional sound systems. This comprehensive mixer features an onboard 24-bit DSP effects processor with 24 preset effects including reverb, delay, chorus, and more, allowing users to quickly enhance their audio with simple channel operation. Designed for performance venues, schools, houses of worship, and mobile setups, the MX9 delivers exceptional audio quality and unprecedented flexibility in a compact form factor.
Equipped with extensive connectivity options, the MX9 accommodates virtually any audio source through its seven balanced XLR mic inputs with 48V phantom power, 1/4" TRS line inputs, and additional unbalanced connections. The integrated media player with display screen supports Bluetooth streaming, MP3 playback, and USB connectivity with recording capabilities, making it a complete solution for today's audio professionals. With professional-grade sound quality, intuitive controls including 3-band EQ per channel, and robust construction, the MX9 excels in both fixed installations and mobile applications where versatility and performance are paramount.
Key Features
- Versatile 9-Channel Design: Comprehensive mixer with 7 balanced XLR/TRS inputs and 2 stereo/mono inputs in a space-saving 3U rack format
- Advanced Effects Processing: Built-in 24-bit DSP processor with 24 professional effects including reverb, delay, vocal echo, and more
- Bluetooth Connectivity: Integrated media player with display screen supporting wireless audio streaming from any Bluetooth device
- Professional Audio Quality: Ultra-low-noise studio-grade mic preamps with 48V phantom power for exceptional sound clarity
- Extensive Channel Controls: Each channel features 3-band EQ, gain control, pan adjustment, pre-fader monitoring, and peak indicator
- Flexible Output Options: Dual stereo main outputs, two auxiliary send groups, and dedicated front-panel headphone monitoring
- USB Functionality: Supports MP3 playback, sound card function, and computer recording capabilities
- Durable Construction: Professional-grade components in a rugged rack-mountable chassis for reliable performance
Technical Specifications
- Mixer Type: 9-channel analog rack mount mixer
- Inputs: (7) XLR mic inputs, (7) ¼" TRS line inputs, (7) ¼" TRS inserts
- Outputs: (1) Set of XLR (L & R), (1) Set of ¼" TRS (L & R), (1) ¼" AUX Out, (1) ¼" FX Out, (1) ¼" Headphone monitor output
- Effects: 24-bit DSP Effects Processor
- Phantom Power: +48V option (Ch 1-7)
- Frequency Response: 20Hz - 20kHz, ± 3 dB
- Distortion: <0.003% (A-weighted)
- Signal-to-Noise Ratio: 60 dB
Additional Specifications
- Microphone Balance Input Noise: -119 dB (A-weighted)
- Single Channel Input Gain: MIC: 0 to 48 dB, LINE: -33 to +15 dB
- Maximum Output Level: +20 dBu
- Mic Input High Pass Filter: 75Hz, 18dB/OCT
- Single-Channel Equalization: High-frequency: ± 15 dB @ 12kHz; mid-frequency: ±12 dB @ 2.5kHz; Low-frequency: ±15 dB @ 80Hz
- Power: Built-in switching power adapter 110-220V, 30W
- Power Consumption: ≤23W
- Dimensions (H x W x D): 5.51" (140 mm) x 19" (483 mm) x 9.45" (240 mm)
- Weight: 8.82 lbs (4 kg)
Package Contents
- Pure Resonance Audio MX9 9-Channel Rack Mount Mixer
- Power cord
- User manual
