VigilLink VLSP-14H21S: 48Gbps 1x4 HDMI 2.1 Distribution Amplifier
The VigilLink VLSP-14H21S is a cutting-edge 1x4 HDMI 2.1 Distribution Amplifier designed to meet the demands of high-definition audio and video distribution. This advanced splitter allows a single HDMI source to be simultaneously displayed on up to four HDMI outputs, ensuring consistent and high-quality signal transmission across all connected displays. With support for video resolutions up to 8K at 60Hz with 4:2:0 chroma subsampling and 12-bit color depth, the VLSP-14H21S delivers stunning visual clarity and detail, making it ideal for applications that require ultra-high-definition content distribution.
Built to comply with HDMI 2.1 and HDCP 2.3 standards, the VLSP-14H21S ensures seamless compatibility with the latest audio and video formats, providing a future-proof solution for your AV setup. The splitter boasts a data rate of up to 48Gbps, accommodating the most demanding high-bandwidth content without compromising performance. Features such as EDID management and cable equalization are integrated to facilitate easy installation and reliable operation, making the VLSP-14H21S a versatile choice for both professional AV installations and home entertainment systems.
Whether you're a gamer seeking to connect your Xbox or PS5 to multiple displays or a professional requiring dependable signal distribution for presentations or digital signage, the VLSP-14H21S rises to the occasion. Its robust design and comprehensive feature set ensure that high-quality audio and video signals are consistently delivered to all connected devices, providing an immersive and uninterrupted viewing experience.
Key Features
- Supports HDMI 2.1 and HDCP 2.3 standards
- Distributes one HDMI source to four HDMI outputs simultaneously
- Supports video resolutions up to 8K@60Hz with 4:2:0 chroma subsampling and 12-bit color depth
- Data rate support up to 48Gbps
- Integrated EDID management and cable equalization
- Compatible with gaming consoles like Xbox and PS5 for 4K@120Hz output
Technical Specifications
HDMI Compliance: HDMI 2.1
HDCP Compliance: HDCP 2.3
Video Bandwidth: 48Gbps
Video Resolution: Up to 8K@60Hz 4:2:0 12-bit
Color Depth: Supports 12-bit color depth
Input Port: 1× HDMI Type A [19-pin female]
Output Ports: 4× HDMI Type A [19-pin female]
ESD Protection: Human-body Model: ±8kV (Air-gap discharge), ±4kV (Contact discharge)
Power Supply: Input: AC100 - 240V 50/60Hz, Output: DC 12V/1A
Power Consumption: 4.08W
Dimensions: 8.03" (W) × 3.74" (D) × 0.85" (H)
Weight: 1.03 lbs
Chassis Material: Metal Enclosure
Silkscreen Color: Black
Operating Temperature: 14°F ~ 113°F (-10°C ~ 45°C)
Storage Temperature: -4°F ~ 140°F (-20°C ~ 60°C)
Relative Humidity: 20 - 90% RH (No condensation)
