JBL AC599-WH 15 Inch 2 Way Full Range Loudspeaker White
AC599 is a compact 2-way full-range loudspeaker system comprised of one 384 mm (15 in) low frequency driver and one 25 mm (1 in) exit/35 mm (1.5 in) voice-coil compression driver. The horn provides 90 by 90 coverage in vertical and horizontal orientation. High-slope passive crossovers minimize band overlap and well-controlled offaxis response. The cabinet is fitted with M10 threaded suspension points. Four threaded inserts located on back of the enclosure allow attachment of an MultiMount or similar type mounting. AC599 is part of JBL's AE Application Engineered Series, a versatile family of loudspeakers for a wide variety of fixed installation applications
Key Features
- Color: White
- Robust 15mm enclosure with black textured finish
- 384 mm (15 in) LF transducer
- 90 x 90 Waveguide with a 25 mm (1 in) exit 35mm (1.5") diaphragm compression driver
- Dual Neutrik NL4 connectors plus screw terminals
- Multiple attachment points for ultimate flexibility
Technical Specifications
Frequency Range (-10 dB)
60 Hz - 20 kHz
Frequency Response (-3 dB)
75 Hz - 18 kHz
System Sensitivity (1w @ 1m)
98 dB
Nominal Impedance
8 ohms
Maximum SPL (1m)
122 dB (128 dB peak)
Power Rating (Continuous/Program/Peak)
250 W/500 W/1000 W
Coverage Pattern
90 x 90 (H x V)
Crossover
1.5 kHz
Low Frequency Driver
1 x 15" woofer (P/N: 5053935), 381 mm (15 in) driver with 38 mm (1.5 in) voice-coil
High Frequency Driver
1 x 2408H-2 driver with 25 mm (1 in) exit/38 mm (1.5 in) voice-coil
Input Connector
Dual Neutrik NL4MP connectors plus covered barrier trip terminals
Enclosure
15 mm multi-ply hardwood plywood
Grille
Powder coated, 1.5mm perforated steel, with acoustically transparent black foam backing
Finish
Textured black paint finish. White (-WH) available upon request. Not available with WRC & WRX finish.
Suspension / Mounting
14 x M10 and 4 x M10 for Wall Mount Bracket. Optional U-bracket, overhead suspension bracket, and wall-mount bracket
