Audio Technica ATW-A49 | UHF Wide-Band Directional LPDA Antennas Pair
The Audio Technica ATW-A49 UHF Wide-Band Directional LPDA Antennas are designed for professionals who demand superior signal pickup and reliability in their wireless system setups. These antennas cover a wide frequency range from 440 to 900 MHz, making them versatile for various applications, including live performances, broadcasting, and permanent installations. Each antenna paddle is engineered with precision, matched to a 50-ohm impedance, and features a high-quality low-loss BNC connector to ensure minimal signal loss and maximum efficiency.
Constructed from copper-clad epoxy fiberglass and finished with a sleek black matte finish, these antennas are not only durable but also aesthetically pleasing. With a typical gain of 6 dB, they offer enhanced performance compared to standard antennas. The elliptical polar pattern with a 90-degree acceptance angle provides consistent and reliable coverage, while the vertical polarization, when mounted vertically, ensures optimal signal reception. Whether you are setting up a new wireless system or upgrading an existing one, the Audio Technica ATW-A49 antennas are a top choice for professionals who value quality and performance.
Installation is a breeze with the 5/8-27 thread mount, which can swivel 90 degrees for flexible positioning. Weighing just 11.5 oz (326 g) each, these antennas are lightweight yet robust, making them suitable for both temporary and permanent setups. With these antennas, you can be assured of crystal clear audio and a robust connection, no matter the environment.
Key Features
- Wide frequency range: 440 - 900 MHz
- 6 dB typical gain for enhanced performance
- 50-ohm impedance for optimal compatibility
- High-quality low-loss BNC connector
- Elliptical polar pattern with 90-degree acceptance
- Vertical polarization for improved signal reception
- Sturdy construction with copper-clad epoxy fiberglass
- Sleek black matte finish
- Lightweight at 11.5 oz (326 g) each
- Flexible mounting with 5/8-27 thread
- 90-degree swivel adaptor for easy positioning
Specifications
- Antenna Type: Log Periodic Dipole Array (LPDA)
- Operating Bandwidth: 440 - 900 MHz
- Gain: 6 dB typical
- Impedance: 50 ohms typical
- VSWR: ≤ 1.7:1 typical
- Polar Pattern: Elliptical, 90-degree acceptance
- Polarization: Vertical (when mounted vertically)
- Number of Elements: 9
- Maximum Power Input: Not specified (intended as receive antenna only)
- Termination Type: Fixed right-angle BNC female connector
- Weight: 11.5 oz (326 g) each
- Dimensions: 10.55 in (268 mm) L x 11.22 in (285 mm) H x 0.98 in (25 mm) D
- Material: Copper-clad epoxy fiberglass
- Finish: Black matte
- Mounting: 5/8-27 thread; adaptor can swivel 90 degrees
Package Contents
- 2 x Audio Technica ATW-A49 UHF Wide-Band Directional LPDA Antennas
- Installation hardware
- User manual
