AtlasIED DPA1202 1200W Networkable Multi-Channel Power Amplifier with Optional Dante Network Audio
The AtlasIED DPA1202 is a feature-rich, network-based 4-channel power amplifier designed to deliver exceptional flexibility and performance for professional audio installations. With onboard DSP and a web-based GUI, the DPA1202 supports versatile configurations such as 2 x 600-Watt at 70.7V or 100V, 4 x 300-Watt at 4Ω, or hybrid setups that combine high and low impedance outputs. The amplifier includes four balanced line inputs and an accessory slot to expand connectivity with an optional Dante™ receiver card or analog mixer card, offering a total of eight input channels.
Ideal for complex commercial applications, the DPA1202 offers comprehensive DSP tools including EQ, high/low pass filters, delay, and limiters—all accessible through browser-based control via PC, tablet, or smartphone. Its integrated Site Manager software provides advanced network discovery, fault reporting, scheduling, and remote management across installations. With remote mute triggers, assignable level controls, and universal voltage compatibility, the DPA1202 is built for reliability and streamlined integration in modern AV environments.
Key Features
- Configurable for 2 x 600-Watt @ 70.7V or 100V
- Configurable for 4 x 300-Watt @ 4Ω or 4 x 150-Watt @ 8Ω
- Optional Hybrid Mode: 1 x 600-Watt @ 70.7V or 100V + 2 x 300-Watt @ 4Ω
- Integrated DSP with EQ, Filters, Delay & Limiters
- Web Browser GUI for Full Configuration & Monitoring
- Supports Dante™ with Optional DPA-DAC4 Card
- Four Balanced Line Inputs with Accessory Slot for Expansion
- Assignable Front Panel or Remote Level Control
- Mute via Audio Signal or Contact Closure
- PC, iOS, and Android Compatible Control
Technical Specifications
- Amplifier Topology: Class AB Switching Hybrid - BASH
- Input Sensitivity: 750mV Balanced, 0dBU
- Input Impedance: 40kΩ Balanced
- Max Input: +14dBU (Inputs 1–4), +7dBU (Dante Inputs 5–8)
- THD: 1% @ Rated Output
- Frequency Response: 20Hz – 20kHz (±3dB, DSP Filters Flat)
- Signal-to-Noise Ratio: -100dB (A-Weighted)
- Crosstalk: 70dB @ 1kHz
- Voltage Compatibility: 110V – 120V & 220V – 240V Auto-Switching
- Idle Power Consumption: 38W
- Rack Size: 1 RU
- Warranty: 36 Months from Date of Purchase
What’s in the box
- DPA1202 Amplifier Unit
- User Documentation
