Turtle AV 30W PoE+ Dante Power Amplifier
Free Shipping
More finance options:
Estimated Shipping Widget will be displayed here!
Orders placed between Monday - Friday before
1:00 PM PST will most likely ship out the same day. We work hard to process and ship your items quickly so you can start enjoying them as soon as possible.
Found a lower price? Contact us and we'll see if we can match it! Price match will only be applied to products sold and shipped by authorized retailers of the brand.
No restocking fee will be charged when you opt for store credit. Exclusions apply.
Condition: New
Description
Turtle AV 30W PoE+ Dante Power Amplifier
The Turtle AV 30W PoE Dante Power Amplifier is a compact, plenum rated amplifier and Dante audio interface designed for classrooms, conference rooms, retail spaces, and small distributed audio zones. It provides two channel Class D amplification along with full Dante digital audio integration, allowing it to function as a Dante to analog output device, an analog to Dante input device, or both simultaneously.
Powered through PoE Plus or an optional 12 VDC supply, this amplifier delivers 2 x 15 W in stereo mode or 1 x 30 W in bridged mono mode for passive speakers. Built in DSP allows fine control over gain, EQ, volume, delay, and presets through a web based interface or external control systems. With support for balanced and unbalanced analog inputs and outputs in addition to Dante digital audio, it provides a flexible solution for modern networked AV systems.
The plenum rated metal housing and compact form factor make installation simple in ceilings, behind displays, on walls, or inside equipment cabinets. With its low profile design and robust Dante feature set, this amplifier is ideal for scalable commercial AV environments.
Key Features
- PoE Plus Powered Amplifier: Operates entirely from PoE Plus power, simplifying installation and reducing cabling.
- Class D Amplification: 2 x 15 W stereo or 1 x 30 W bridged output for passive speakers.
- Dante and Analog Bridge: Functions as Dante to analog, analog to Dante, or simultaneous bi directional audio bridge.
- Built in DSP: Gain, EQ, volume, delay, and preset management through Web GUI or external control.
- Balanced and Unbalanced Analog I O: Supports professional and consumer level audio sources.
- Compact Plenum Rated Housing: Safe for above ceiling installation with a low profile metal chassis.
- Dante AES67 Compatible: Works seamlessly in Dante and AES67 networked audio systems.
Technical Specifications
- Amplifier Output: 2 x 15 W stereo at 4 or 8 ohm, or 1 x 30 W bridged mono at 4 or 8 ohm
- Audio Formats: Dante PCM, 48 kHz, 24 bit
- Inputs: Dante network audio, balanced or unbalanced analog line or mic input
- Outputs: Speaker output for 4 8 ohm loads, balanced or unbalanced line output
- DSP Features: Input gain, EQ, delay, volume, preset recall
- Dante Latency: Configurable to 2, 3, 4, 5, or 10 ms
- Analog Output Latency: Adjustable from 0 to 50 ms
- Frequency Response: 20 Hz to 20 kHz
- Signal to Noise Ratio: Greater than 100 dB A weighted
- THD plus N: Less than 0.01 percent at +4 dBu, 1 kHz
- Input Impedance: 20 kohm balanced, 10 kohm unbalanced
- Network Bandwidth: 100 Mbps Dante network
- Power Options: PoE Plus IEEE 802.3at Class 4 or 12 VDC
- Enclosure: Metal, plenum rated
- Dimensions: 7.09 in x 4.65 in x 0.91 in
- Weight: 1.57 lbs
