DSC PGP9986 PowerG Plus Water Tile with Freeze Detection

DSC PGP9986 PowerG Plus Water Tile with Freeze Detection

The DSC PGP9986 PowerG+ Water Tile is a wireless water and freeze detector designed to provide early warning of leaks, flooding, and low-temperature conditions. Operating in the 912-919 MHz band, it combines two-way PowerG and PowerG+ communication, an audible leak alarm, IP65 protection, and freeze detection below 41°F.

Designed for residential and professional security installations, the low-profile sensor can monitor areas near plumbing, appliances, utility rooms, basements, and other locations vulnerable to water damage. Integrated electrodes detect water directly, while optional sensing-cable and external-probe accessories expand coverage or allow vertical mounting. LED indicators assist with signal-strength assessment, and enhanced tamper monitoring covers the device, mounting position, and connected probes.

The PGP9986 supports compatible IQ Panel systems and can also operate with additional PowerG-enabled platforms in legacy or fallback configurations. Freeze functionality depends on the connected panel and operating mode. Two CR2450 lithium batteries provide up to five years of typical battery life, while low-battery reporting, over-the-air firmware capability, a multifunction enrollment/reset/mute button, and an integrated buzzer support ongoing system operation and service.

Key Features

• Water and Freeze Detection: Detects leaks or flooding and reports low-temperature conditions below 41°F when supported by the connected system.
• PowerG+ Wireless Communication: Uses secure two-way PowerG and PowerG+ communication with FHSS and TDMA technologies for dependable wireless connectivity.
• Audible Leak Alert: An integrated buzzer provides a local warning when water is detected.
• Enhanced Tamper Detection: Monitors the cover, mounting condition, and connected external probes for improper installation or interference.
• Flexible Sensor Expansion: Supports optional external probes and sensing cables for expanded water-detection coverage.
• IP65 Protection: The protected enclosure suits floor-level placement in indoor areas where moisture exposure may occur.
• Up to Five-Year Battery Life: Two CR2450 lithium batteries provide extended operation under typical room-temperature use.
• Service and Status Functions: LED indication, low-battery reporting, a multifunction enrollment/reset/mute button, and supported firmware updates simplify system management.

Technical Specifications

• Brand: DSC
• Model: PGP9986
• Product Type: Wireless water and freeze detector
• Regional Model: North America and Latin America
• Frequency Band: 912-919 MHz
• Maximum Transmit Power: +18 dBm at 915 MHz
• Modulation: GFSK
• Communication Protocol: PowerG, PowerG+
• Wireless Technology: Two-way FHSS and TDMA communication
• Water Detection: Integrated electrodes
• Freeze Detection Threshold: Below 41°F
• Audible Alert: Integrated buzzer
• Visual Indicator: LED
• Controls: Multifunction enrollment, reset, and mute button
• Tamper Detection: Cover, mounting, and external probe monitoring
• External Sensor Support: External probe and sensing cable accessories
• Firmware Updates: Over-the-air updates supported
• Battery Reporting: Supported
• Dealer Lockdown: Supported
• Power Supply: Battery
• Battery Type: 2 x 3V CR2450 lithium batteries
• Specified Battery Brands: Panasonic, Duracell, GP
• Typical Battery Life: Up to 5 years at 77°F
• Nominal Operating Voltage: 6V
• Low Battery Threshold: 4.3V at 77°F
• Maximum Current Consumption: 100 mA
• Minimum Current Consumption: 2 µA
• Quiescent Current: 7.5 µA after at least 1 hour of inactivity
• Ingress Protection: IP65
• Operating Temperature: 14°F to 131°F
• UL Evaluated Operating Temperature: 32°F to 120°F
• Storage Temperature: -4°F to 158°F
• Relative Humidity: Up to 93%, non-condensing
• Dimensions: 2.6 x 2.6 x 0.4 inches
• Weight: 0.1 lb including batteries
• Color: White
• Compatible Panels: IQ Panel 4, IQ Panel 5, IQ4 Hub, IQ4-NS, IQ Pro, IQ5 Hub, IQ5 NS
• Legacy Compatibility: Additional PowerG-enabled panels supported in legacy/fallback mode with flood-only functionality
• Optional Accessory: PGP-WT-PRB wall-mount bracket and external sensor probe kit
• Optional Accessory: PGP-WT-SC6 wall-mount bracket and 6 ft sensing cable kit

What's In the Box

• PGP9986 Water Tile
• Manual
• 0.5 x 0.5 Inch Double-Sided Mounting Tape
