AJA HI5-4K 3G-SDI to HDMI 2.0 Conversion Card with DashBoard Support
AJA HI5-4K is an openGear conversion card designed for professional video monitoring environments. It enables conversion of 3G-SDI video sources to HDMI 2.0 for engineers and operators, supporting broadcast and production workflows. This makes it ideal for facilities where accurate HDMI monitoring from SDI infrastructure is critical.
The card converts Quad or Dual 3G-SDI inputs to HDMI 2.0 output with support for multiple pixel-mapping methods. It operates within compatible openGear frames and integrates with DashBoard software for configuration and monitoring. HDR metadata handling is supported in accordance with HDMI standards.
This card allows seamless monitoring of SDI-based video sources on HDMI displays. It supports modern UHD and HDR workflows while maintaining compatibility with HD and SD formats. Users can deploy it in broadcast, post-production, and live production systems requiring reliable SDI-to-HDMI conversion.
Key Features
- 3G-SDI to HDMI 2.0 Conversion: Enables monitoring of SDI sources on HDMI displays
- openGear Compatible Card: Designed for use in certified openGear frames
- 4K UltraHD Support: Converts Quad 3G-SDI signals up to 4K 60p
- HDR Metadata Support: Supports HDR10 and HLG signaling
- DashBoard Software Control: Provides remote configuration and monitoring over Ethernet
Technical Specifications
Format Support4K UltraHD
2K
HD
SD
SDI Input Audio
16-Channel Embedded Audio
HDMI Output Audio
8-Channel Embedded Audio
HDCP Support
Yes
HDR Support
HDR10
HLG
Embedded Audio Support
8-channel 24-bit
AC-3 Dolby Digital
E-AC-3 Dolby Digital Plus
DD+ Atmos JOC
Pixel Mapping
Two Sample Interleave 2SI
Square Division Quadrant
OS Compatibility
Windows
macOS
Linux
Power Consumption
12 W
Installation
Hot-swappable
Two openGear slots required
Rear I/O card included
Frame Compatibility
OG-X-FR
OG-3-FR
DFR-8321
Certifications
BSMI Class A
CE
FCC Part 15 Class A
ICES-003 Class A
Kcc
VCCI Class A
What’s in the Box
(1) AJA HI5-4K 3G-SDI to HDMI 2.0 Conversion CardLimited 5-Year Manufacturer Warranty
