Digital Forecast UHD X_GEN 12G-SDI HDMI2.0 Test Pattern Generator and Recorder
Free Shipping
More finance options:
Estimated Shipping Widget will be displayed here!
Orders placed between Monday - Friday before
1:00 PM PST will most likely ship out the same day. We work hard to process and ship your items quickly so you can start enjoying them as soon as possible.
Found a lower price? Contact us and we'll see if we can match it! Price match will only be applied to products sold and shipped by authorized retailers of the brand.
No restocking fee will be charged when you opt for store credit. Exclusions apply.
Condition: New
Description
Digital Forecast UHD X_GEN 12G-SDI HDMI2.0 Test Pattern Generator and Recorder
Digital Forecast UHD X_GEN is a test pattern generator and recorder designed for professional AV and display validation environments. It enables generation, conversion, and recording of video signals for technicians, supporting UHD, FHD, and HD workflows. This makes it ideal for testing multiple display devices where signal verification is critical.
The unit outputs test patterns over SDI and HDMI and can simultaneously record UHD signals from an HDMI input. It also accepts HDMI input, converts it to UHD, and outputs through both SDI and HDMI interfaces.
The device is used during installation, commissioning, and troubleshooting of video systems. It supports consistent validation of signal paths and display performance across different resolutions.
Key Features
- Test Pattern Generation: Supports still image and moving video patterns
- Signal Conversion: Converts HDMI input to UHD for SDI and HDMI outputs
- Simultaneous Operation: Allows pattern output and recording at the same time
- Recording Support: Records UHD video via SD card from HDMI input
- Multi-Display Testing: Designed to test multiple display devices
Technical Specifications
Product TypeTest Pattern Generator and Recorder
HDMI Input
1 x HDMI 2.0
HDMI Output
2 x HDMI 2.0
SDI Output
4 x 12G SDI
Supported Resolutions
HD
FHD
UHD
Pattern Support
Still image patterns
Video moving patterns
Recording Media
SD card
Network Support
Pattern data management
Whatās in the Box
(1) Digital Forecast UHD X_GEN Pattern Generator(1) Power Adapter
