Portkeys BM7 II-DS 7-Inch High-Bright Monitor with Wireless Camera Control
Built for professionals who demand exceptional clarity and control on set, the Portkeys BM7 II DS delivers uncompromising performance in a compact 7" form factor. With a stunning 2200-nit display, this monitor remains clearly visible even under direct sunlight, making it ideal for outdoor shoots and high-light environments. The Full HD 1920 x 1080 resolution ensures sharp image detail, while its rugged aluminum alloy construction guarantees long-lasting durability in the most demanding production conditions.
Designed for versatility, the BM7 II DS supports both 3G-SDI and HDMI inputs and outputs, allowing seamless integration into a wide variety of camera systems and workflows. Built-in HDMI-to-SDI signal conversion ensures maximum flexibility on set, and the monitor also includes dual 3G-SDI inputs for redundant signal paths. Whether you’re working with professional cinema cameras or DSLR/mirrorless systems, this monitor offers reliable compatibility and high-performance monitoring.
With its integrated fan cooling system, wide viewing angles, and support for professional power sources, including Sony NP-F series batteries and LEMO/DC input, the BM7 II DS is designed to work wherever your production takes you. Additional features such as 3D LUT support, firmware updates via USB-A, and a built-in camera control port (compatible with focus pullers and remote triggers) make this monitor a powerful addition to any production rig.
Key Features
- 7" Full HD display with 1920 x 1080 resolution
- 2200 nits peak brightness for daylight visibility
- 85% DCI-P3 color gamut coverage for accurate color monitoring
- Dual 3G-SDI inputs with HDMI input/output
- Supports HDMI-to-SDI HD signal conversion
- Wide 85° viewing angles in all directions
- Aluminum alloy construction for enhanced durability
- Built-in cooling fan and low maximum power draw (15W)
- Supports Sony NP-F970/F960/F750/F550 batteries
- Camera control port for focus puller and remote triggers
Technical Specifications
Screen Size: 7"
Dimensions: 7.06" x 4.2" x 1.22" (179.3 x 106.8 x 31 mm)
Viewing Angle: 85° / 85° / 85° / 85°
Brightness: 2200 nits
Resolution: 1920 x 1080
Contrast Ratio: 1000:1
Weight: 1.01 lbs (460 g)
Color Gamut: 85% DCI-P3
Maximum Power: 15 W
Antenna: 2.4 GHz
Fan: Yes
Material: Aluminum Alloy
Video Signal Input: 2x 3G-SDI, 1x HDMI
Video Signal Output: 1x 3G-SDI, 1x HDMI
Signal Conversion: HDMI to SDI (HD output)
Camera Control Port: Focus Puller / Camera Remote
Input Voltage: 7–24 VDC
Support Battery Model: Sony NP-F970 / F960 / F750 / F550
USB-A: Firmware Update / 3D LUT
Power Input / Output: 2-Pin LEMO / DC 5.5 x 2.1 mm
Audio Output: 3.5 mm Headphone Jack
What’s Included
- Portkeys BM7 II DS 7" Monitor
- Pre-installed Battery Plate (Sony NP-F Series Compatible)
- LEMO to D-Tap Power Cable
- USB Drive (for Firmware & LUT Upload)
- User Manual
