Vaddio 998-8250-000 Dante AV Bridge 2x1 Dante Audio Matrix
The Vaddio AV Bridge 2x1 (Model 999-8250-000) is a versatile and robust presentation switcher designed to seamlessly integrate professional AV sources into software conferencing platforms and live streaming applications. With dual HDMI inputs, it allows users to switch between two video/audio sources, such as a camera and a PC display, and output them simultaneously via USB 3.0, HDMI, and IP streaming, all at up to 1080p60 resolution. This capability makes it ideal for lecture capture, conference rooms, and video conferencing installations.
Equipped with a 4x4 Dante audio matrix, the AV Bridge 2x1 offers scalable networked audio solutions, supporting up to 12x12 cross-point audio routing. It also provides two balanced microphone/line-level audio inputs and outputs, ensuring high-quality audio capture and playback. The device supports Power-over-Ethernet (PoE+) for simplified installation and includes a browser-based user interface for easy configuration and control. Additionally, it features built-in automation capabilities, allowing for trigger devices to control camera presets, source selection, and more, enhancing the overall production value.
Key Features
- Dual HDMI Inputs: Switch between two video/audio sources, such as a camera and a PC display.
- Simultaneous Outputs: USB 3.0, HDMI, and IP streaming outputs at up to 1080p60 resolution.
- 4x4 Dante Audio Matrix: Scalable networked audio with up to 12x12 cross-point routing.
- Balanced Audio I/O: Two microphone/line-level audio inputs and outputs for high-quality audio handling.
- Power-over-Ethernet (PoE+): Simplifies installation by combining power, control, and streaming over a single Ethernet cable.
- Automation Support: Built-in automation features allow trigger devices to control camera presets, source selection, and more.
Technical Specifications
- Video Inputs: 2 x HDMI Type A
- Video Output: 1 x HDMI Type A, 1 x USB 3.0 Type-B
- Audio Inputs: 2 x 3-Pin Terminal Block, Mic/Line Input
- Audio Outputs: 2 x 3-Pin Terminal Block, Mic/Line Output
- IP Streaming: RTSP or RTMP up to 1080p30
- Control Interfaces: 1 x RJ45 Ethernet, 1 x 3-Pin Terminal Block (Trigger), 1 x RJ45 RS-232
- Power: PoE+ (48 VDC, 10 mA)
- Dimensions: 8.38" W x 6.0" D x 1.72" H (21.3 x 15.2 x 4.4 cm)
- Weight: 2.65 lbs (1.2 kg)
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Certifications: CE, FCC, TAA Compliant
What's Included in the Box
- Vaddio AV Bridge 2x1 Presentation Switcher
- PoE+ Power Injector
- Power Injector Cable
- 3' Cat-5 Cable
- 6' USB 3.0 Type-A to Type-B Cable
- 6 x 3-Pin Terminal Connectors
- Half-Rack Mounting Kit
- Quick-Start Guide
