VLPT-52K2HD HDMI Switcher with USB-C and Multiple Audio Outputs
The VLPT-52K2HD is a versatile HDMI switcher designed to meet the demands of professional AV setups, offering seamless video and audio switching with high-quality outputs. This device supports up to 4K2K resolution at 60Hz with 24-bit RGB/YCBCR 4:4:4, ensuring crisp and clear visuals for any presentation, meeting, or live event. It is fully compliant with HDCP 2.2, making it compatible with modern content protection standards. Additionally, the switcher allows for easy integration with other AV devices through its wide array of input and output ports, including HDMI, USB-C, and audio options.
Engineered for high performance, the VLPT-52K2HD features robust video bandwidth capabilities, supporting up to 18Gbps to ensure smooth, lag-free video transmission. Audio support is equally comprehensive, with the switcher handling LPCM, AC3, DD+, DTS, and DTS-HD audio formats up to 7.1 channels. This makes it an excellent choice for setups that require both high-quality video and immersive audio output. Its metal enclosure offers durability while its sleek black finish ensures a professional look that complements any environment.
The VLPT-52K2HD is equipped with multiple control options, including RS232, LAN, and USB-A for easy management and integration with existing control systems. Its compact size and low power consumption (15W max) make it ideal for small to medium-sized installations, while its wide operating temperature range and reliable ESD protection ensure dependable performance even in challenging environments.
Key Features:
- Supports up to 4K2K at 60Hz with 24-bit RGB/YCBCR 4:4:4
- HDCP 2.2 compliance for modern content protection
- Video bandwidth of 18Gbps for smooth, high-quality video transmission
- Audio support for LPCM, AC3, DD+, DTS, DTS-HD up to 7.1 channels
- 4 x HDMI IN, 1 x USB-C, and 4 x USB-B (Host) inputs
- 2 x HDMI OUT, 2 x USB-A (Device), 1 x L/R AUDIO OUT, and 1 x Toslink digital audio outputs
- Control via RS232, LAN, or USB-A for easy integration
- Compact, metal housing with black finish for professional appearance
- Low power consumption (15W max) and durable metal enclosure
Technical Specifications:
Dimensions: 8.62" x 5.75" x 1.73"
Weight: 2.65 lbs
Power Supply: DC 12V/3A
Power Consumption: 15W (Max)
Input Ports: 4 x HDMI IN [Type A, 19-pin female], 1 x USB-C, 4 x USB-B (Host)
Output Ports: 2 x HDMI OUT [Type A, 19-pin female], 2 x USB-A (Device), 1 x L/R AUDIO OUT [3.5mm Jack], 1 x Toslink digital audio
Control Ports: 1 x RS232 [4-pin phoenix connector], 1 x LAN [RJ45 connector], 1 x SERVICE [USB-A]
Housing: Metal Enclosure
Color: Black
Operating Temperature: 32°F ~ 104°F (0°C ~ 40°C)
Storage Temperature: -4°F ~ 140°F (-20°C ~ 60°C)
Relative Humidity: 20 - 90% RH (No condensation)
ESD Protection: ±8kV (Air-gap discharge), ±4kV (Contact discharge)
