Samson Mic Splitter Signal Routing Box
The Samson Mic Splitter is a compact and durable passive signal splitter designed for routing a microphone or line-level audio signal into up to three separate destinations. With a rugged steel enclosure, this device is ideal for live sound, podcasting, streaming, and studio recording environments where flexibility and reliability are essential.
Featuring an XLR/TRS combo input with a mic/line toggle, the Mic Splitter allows users to connect a wide variety of audio sources. Two isolated XLR outputs and an additional direct XLR output offer multiple routing paths, while ground lift switches on each split output help eliminate unwanted hum and noise from the signal chain.
Whether used in a mobile rig or fixed setup, the Samson Mic Splitter delivers pro-grade signal distribution in a minimal form factor. It’s built for reliability on stage or in the studio, providing an efficient solution for parallel processing, dual system feeds, or live streaming setups.
Key Features
- Versatile Input: XLR/TRS combo input with mic/line gain toggle
- Multiple Outputs: Two parallel XLR outputs and one direct XLR output
- Ground Lift Switches: Independent ground lifts for each split output
- Durable Build: All-metal steel enclosure for rugged reliability
- Compact Design: Fits easily into any studio or live rig
Technical Specifications
- Input Connector: XLR / TRS combo
- Split Outputs: 2 × XLR
- Thru Output: XLR
- Ground Lift Switches: Yes (for each split output)
- Enclosure: Steel
- Dimensions (unit): 5.0 × 3.75 × 1.75 in (127 × 86 × 49 mm)
- Weight (unit): 1.47 lb (0.667 kg)
- Packaging Dimensions: 5.5 × 4.25 × 2.25 in (140 × 108 × 57 mm)
- Packaged Weight: 1.62 lb (0.735 kg)
- Model: Mic Splitter
What’s in the Box
- 1x Samson Mic Splitter Signal Routing Box
