Sony URX-P03D/14 UWP-D 2 Channel Portable Wireless Receiver, UC14, 470 to 542 MHz
The URX-P03D 2-channel portable receiver forms part of a complete UWP-D audio system offering the sound quality of digital audio processing combined with the reliability of analog FM modulation. The URX-P03D offers wide frequency coverage with up to 72 MHz bandwidth (depending on region) across a wide range of channels, with a choice of models to choose from. Easy-to-use features include a large display and small size to fit neatly on any size camcorder or DSLR camera, automatic channel setting function, headphone output, USB connection for power supply and line input availability. The receiver also has external mic input for an additional wired microphone and 3 channel mixer function. The UWP-D Series system provides superb transient response performance for all ENG / EFP production applications.
Key Features
- UWP-D digital audio processing for high quality sound
- External mic input for additional wired microphone with 3 channel Mixer function
- Fast and easy channel scan
- Large display and small size receiver
- Automatic channel setting mode
- Wide frequency coverage
- Compatibility with Sony 800 and UWP Series analog audio receivers
- USB for external power supply or charging batteries
Technical Specifications
Oscillator Type
Crystal-controlled PLL Synthesizer
Reception Type
Space diversity*
Antenna Type
1/4 wave length wire
Carrier Frequencies: Americas
14UC: 470.125 MHz to 541.875 MHz (UHF-TV channels 14 to 25)
25UC: 536.125 MHz to 607.875 MHz (UHF-TV channels 25 to 36)
42LA: 638.125 MHz to 697.875 MHz (UHF-TV channels 42-51) (not available in U.S. or Canada)
Carrier Frequencies: Europe, UAE, South Africa, Australia, Malaysia, Vietnam, New Zealand
CE21: 470.025 MHz to 542.000 (not available in Australia, Malaysia, Vietnam or New Zealand)
CE33: 566.025 MHz to 633.000 MHz (not available in New Zealand)
CE42: 638.025 MHz to 694.000 MHz
Carrier Frequencies: China
CN38: 710.025 MHz to 782.000 MHz
Carrier Frequencies: Thailand, Taiwan, Singapore
E: 794.125 MHz to 805.875 MHz
Carrier Frequencies: Japan
JB: 806.125 MHz to 809.750 MHz
Carrier Frequencies: South Korea
KR3: 925.125 MHz to 937.500 MHz
Frequency Response
23Hz to 18kHz (typical)
Signal-to-Noise Ratio
96dB (max deviation, A-weighted)
Distortion (T.H.D)
0.9% or less (-60dBV, 1kHz input)
Audio Delay
Approx. 0.375 msec
Analog Input
3-pole mini jack, unbalanced
Analog Input Level
-50dBV (-12dB Adjustable, 3-dB step)
Analog Output
3-pole mini jack, unbalanced
Analog Output Level
-60dBV (at -5kHz deviation)
Analog Output Adjust Range
-12dB - +12dB (3dB step)
Headphone Output
3.5 mm ( 5/32 inch) stereo mini jack
Headphone Output Level
5 mW (at 16-ohm load)
Pilot Tone Signal
32 kHz/ 32.382 kHz/ 32.768 kHz
Display
LCD
Power Requirements
DC 3.0 V (with two AA-size alkaline (LR6) batteries)
DC 5.0V (via USB micro-B)
Battery Operating Time
Approx. five hours with Sony's AA-size alkaline (LR6) batteries at 25C (77F)
Operating Temperature
0C to 50C
32F to 122F
Storage/Transport Temperature
-20C to +55C
-4F to +131F
Dimensions
63 x 82 x 28.4 mm (excluding the anntenas) (W x H x D)
Mass
Approx. 210 g (including batteries)
