AtlasIED 8x8 I/O Breakout Boxes for BlueBridge DSP Systems
The AtlasIED BB-88 and BB-88DT breakout boxes provide essential analog I/O expansion for BlueBridge DSP audio systems. These compact 1RU units offer 8 balanced analog inputs and 8 balanced analog outputs via DB-25 connectors, delivering professional-grade audio interfacing in a streamlined rackmount form factor. Designed for quick installation and reliable operation, both models include an external locking power supply and a rear-panel USB port for configuration and service access.
The BB-88 serves as the standard analog breakout box for BlueBridge DSP systems without network audio functionality. The BB-88DT adds Dante™ digital audio networking capability, enabling seamless integration with Dante-enabled devices over Ethernet for networked audio distribution. These breakout boxes are ideal for AV environments requiring moderate channel counts with flexible deployment options.
Key Features (All Models)
- 8 analog inputs and 8 analog outputs on DB-25 connectors
- Balanced line-level audio for clean signal transmission
- 1RU rack-mount design for efficient space utilization
- Rear USB port for easy configuration and diagnostics
- External locking power supply included
Model Comparison and Technical Specifications
Model: AtlasIED BB-88
- Network Connectivity: None
- Inputs: 8 analog line-level (DB-25)
- Outputs: 8 analog line-level (DB-25)
- Height: 1.75-Inch
- Width: 19.0-Inch
- Depth: 10.0-Inch
- Weight: 7.5 lbs
- Power Supply: External (included)
Model: AtlasIED BB-88DT
- Network Connectivity: Dante™ Audio-over-IP
- Inputs: 8 analog line-level (DB-25)
- Outputs: 8 analog line-level (DB-25)
- Height: 1.75-Inch
- Width: 19.0-Inch
- Depth: 10.0-Inch
- Weight: 7.5 lbs
- Power Supply: External (included)
What’s Included (All Models)
- BB-88 or BB-88DT Breakout Box (pre-assembled)
- External Locking Power Supply
- Rear USB Port for Configuration
