Red Panda Bit Mixer for Pedalboards
The Bit Mixer is a small, high-quality mixer designed for pedalboards. It features ultra-low distortion, low noise op amps. High-impedance inputs are designed for guitar, but work with line level signals as well. Each input has a volume knob that goes from off to unity gain. Only 4.4ā x 2.6ā, and works with standard pedal power supplies from 9-18 V. Designed and assembled in USA.
Key Features
- Connect multiple instruments to one amp
- Combine parallel effects chains
- Clean blend or analog dry path
Technical Specifications
Size
4.4" x 2.6" x 1.5"
Input impedance
1 M?
Output impedance
< 1 k
Frequency response ( 3 dB)
20 Hz - 40 kHz
Signal-to-noise ratio
90 dB
Power
9-18 VDC, center negative
Current
40 mA
