Camplex TACNGO-FIDO 12G-SDI Video Tactical Fiber Optic Cable Reel Extender System, 1000 Foot
Camplex TACNGO-FIDO 12G-SDI Video Tactical Fiber Optic Cable Reel Extender System, 1000 Foot
The field production and on-location choice for fast deployment and simplified extension of 12G-SDI video over fiber is the Camplex Tac-N-Go FIDO. It is the perfect solution for running camera signals to your production switcher or production switcher output signals to playout. It's also a great solution for monitoring on remotes where the director sits in a warm and tidy truck while the camera crew braves the weather. The system employs the AJA FIDO 12G-SDI fiber converters combined with a field tough LC tactical fiber cable reel.
Key Features
- Rugged Cable Reel for Fast and Easy Field Deployment
- 12G-SDI Fiber Converter
- Simplex connection (LC connector)
- 12G/3G/HD/SD-SDI INPUT
- Reclocked loop through of SDI input
Technical Specifications
Video Formats
100 Mbps - 12 Gbps, format agnostic
Video Input Digital
1-Channel independent 12G-SDI, SMPTE-259/292/424/2081/2082
Video Output Digital
1-Channel independent 12G-SDI Loop out, SMPTE-259/292/424/2081/2082; 1-Channel Single Mode LC Fiber connector, SMPTE-297/259/292/424/2081/2082
Nominal Wavelength
1310 nm
Reclocking
270 Mbps, 1.483 Gbps, 1.485 Gbps, 2.967 Gbps, 2.970 Gbps, 5.934 Gbps, 5.940 Gbps, 11.868 Gbps, 11.880 Gbps - Auto Select; All other rates are passed through and not reclocked
Item Includes
(1) AJA-FIDO-T-12G 1-Channel 12G-SDI to Single-Mode LC Fiber Transmitter
(1) AJA FiDO-R-12G 1-Channel 12G-SDI to Single-Mode LC Fiber Receiver
(2) universal power supplies
(2) LC to ST fiber adapters
3M Dual Lock fasteners
1000 ft tactical fiber cable on reel
