Sharp AQUOS BOARD 4W-B Series 65-Inch 4K LED Interactive Display

Sharp AQUOS BOARD 4W-B Series 65-Inch 4K LED Interactive Display

The Sharp AQUOS BOARD 4W-B65FT5U is a versatile 65-inch interactive display designed for seamless collaboration in business, educational, and professional settings. With its impressive 4K resolution (3840x2160), this display ensures ultra-sharp visuals, offering crisp details and vivid colors for a truly engaging viewing experience. The 4W-B65FT5U is perfect for meetings, presentations, and interactive learning, allowing multiple users to engage simultaneously with up to 20 touchpoints. Its sleek design and powerful functionality make it a valuable tool in any professional environment, providing both performance and flexibility.

With advanced features such as built-in multimedia player support, intuitive touch functionality, and a range of connectivity options, the AQUOS BOARD makes it easy to integrate into any workspace. Whether you’re presenting dynamic content, collaborating in real-time, or conducting virtual meetings, the AQUOS BOARD provides smooth interaction with its LED backlight technology, offering a brightness of 300 cd/m² and a wide viewing angle of 178°. Additionally, with its built-in speakers, closed captioning, and programmable timer, the display offers all the necessary features for efficient communication and collaboration.

The Sharp AQUOS BOARD 4W-B65FT5U is designed for ease of use, offering external control capabilities via RS-232C and LAN, along with USB 2.0 ports for flexible connectivity with media players, external devices, or USB peripherals. With its 3-year warranty, durability, and energy-efficient features such as ECO mode, the AQUOS BOARD is an excellent choice for long-term, professional use.

Key Features

• 65-inch 4K resolution (3840 x 2160) for vibrant, detailed visuals
• Up to 20 simultaneous touchpoints for collaborative interaction
• LED Direct-lit backlight for enhanced brightness and color accuracy
• Built-in multimedia player for seamless content playback
• Wide connectivity options, including HDMI, USB 2.0, and RS-232C
• Integrated speakers for clear audio during presentations and meetings
• Power management features including a sleep timer and programmable timer
• Environmental-friendly with low standby power consumption
• SHARP Pen Software® and Pen-on-paper® technology for interactive use
• 3-year limited warranty for peace of mind

Technical Specifications

Display Panel Technology: TFT LCD
Viewable Image Size: 65" (165 cm)
Aspect Ratio: 16:9
Native Resolution: 3840 x 2160 (4K UHD)
Supported Resolutions: 640 x 480, 720 x 400, 800 x 600, 1024 x 768, 1360 x 768, 1280 x 1024, 1400 x 1050, 1280 x 720p, 1920 x 1080, 1920 x 1080i, 1920 x 1080p, 3840 x 2160, 3840 x 2160p, 640 x 480p, 720 x 480p, 720 x 576p, 720(1440) x 480i, 720(1440) x 576i
Module Resolution: 3840 x 2160
Pixel Pitch: 0.372 mm
Pixels Per Inch: 68 PPI
Backlight Type: LED Direct-lit
Brightness (typical): 300 cd/m²
Contrast Ratio (typical): 1300:1
Viewing Angle (typical): 178°/178° (CR ≧ 10)
Refresh Rate: 60Hz
Active Screen Area: 57.13" x 33.07" / 1451 x 840 mm
Orientation: Landscape
Displayable Colors: 1.07 billion
Synchronization Range: Horizontal (Analog/Digital) 31.5kHz - 135.0kHz, Vertical 24Hz-75Hz

Signal Compatibility/Connectivity

PC Signal Compatibility: Yes
Macintosh Signal Compatibility: Yes
External Control: LAN In/Out and RS232 In - Full external control capabilities
Input Terminals:

• HDMI (2.0 x 3 with HDCP 2.2)
• RS-232C, LAN (100Mb), USB Card (Media Player)
• USB 2.0 x 2 (Media Player, USB (Service), USB Type-C (Touch), USB 1 x 5V/2A Powered)

Output Terminals:

• Audio: 3.5mm-diameter stereo mini jack x 1
• External Control: D-sub 9 pin x 1

Power Consumption

On: 180W
ECO Mode Standby: 0.5W

Physical Specifications

Bezel Width (Left/Right, Top/Bottom): 0.63 in./0.63 in., 0.63 in./0.67 in. : 16 mm/16 mm, 16 mm/17 mm
Dimensions (WxHxD) Without Stand: 58.43 x 34.37 x 3.31 in. / 1484 x 843 x 84 mm
Net Weight (without stand): 69 lbs. / 31.3 kg
Shipping Weight: 88.18 lbs
VESA Hole Configuration: 300mm x 200mm (M6 x 4-hole)

Environmental Conditions

Operating Temperature: 32°F to 104°F (0°C to 40°C)
Operating Humidity: 20% to 80% (no condensation)
Limited Warranty (parts & labor): 3 years

Additional Features

• 4K Ready
• 60 Hz LED Frame Rate
• Built-In Closed Captioning
• Built-In NTSC/ATSC analog/digital tuner
• Built-In Speakers
• Integrated MultiMedia Player
• LED Backlight
• Power Management
• Programmable Timer
• Sleep Timer
• Wired Network Connection
• RS-232C and LAN control capability
• TAA Compliant
• SHARP Pen Software® and Pen-on-paper®
• Contrast Ratio (1300:1)

Accessories Included

• Remote control unit x 1
• Remote control battery ("AAA") x 2
• Setup Guide x 1
• RS232C conversion cable (3.5mm-diameter mini stereo jack) x 1
• Touch Pen x 2
• USB cable x 1
• USB adapter x 1
• USB flash drive (Utility for Windows) x 1
