Sharp PN-HB651 65 Inch Versatile High-Definition Signage Display

The PN-HB851/HB751/HB651 is a monitor you can trust to get your message out there. What sets it apart is a built-in system-on-a-chip (SoC) controller that allows it to deliver digital signage straight out of the box. Daily operation is a breeze, thanks to on-board content distribution software. Also, SHARP e-Signage S allows you to create and manage professional-grade content. And optional upgrades give the monitor even more flexibility to interact with external devices. It all adds up to a powerful signage solution that’s built to engage.

Key Features

• Built-in SoC (System on a Chip)
• Support for H.265/HEVC
• SHARP Open Architecture Platform
• Smart Connectivity
• Superb 4K LCD Panel
• Autoplay with Media Player
• Web-Based Signage

Technical Specifications

Installation
Landscape / Portrait / Face-up
LCD Panel
85-inch-class (84 9/16-inch <214.78 cm> diagonal) TFT LCD
Max. Resolution
3,840 x 2,160 pixels
Max. Display Colours (approx.)
1,070 million colours
Pixel Pitch (H x V)
0.488 x 0.488 mm
Max. Brightness
350 cd/m2
Contrast Ratio
5,000 : 1
Viewing Angle (H/V)
178/178 (CR 10)
Active Screen Area (W x H)
1,872 x 1,053 mm (73 11/16" x 41 7/16")
Response Time
9.5 ms (grey to grey, avg.)
Backlight
LED, direct lit
Computer Input
Video
Analogue RGB (0.7 Vp-p) <75>, DisplayPort 1.2, HDMI
Synchronisation
Horizontal/vertical separation (TTL: positive/negative)
Plug & Play
VESA DDC2B
Input Terminals
DisplayPort x 1, Mini D-sub 15-pin x 1, HDMI x 2, RS-232C x 1, 3.5 mm-diameter mini stereo jack x 1
Output Terminals
DisplayPort x 1, RS-232C x 1*3, 3.5 mm-diameter mini stereo jack x 1
Dimensions (W x D x H) (approx.) (display only)
1,902 x 89 x 1,083 mm (74 7/8" x 3 1/2" x 42 5/8")
Weight (approx.)
48 kg (105.9 lbs)
