Sony UTX-B03/14 UWP-D Bodypack Transmitter with Omnidirectional Lavalier, UC14, 470 to 542 MHz
Sony UTX-B03/14 UWP-D Bodypack Transmitter with Omnidirectional Lav...
Free Shipping
Sony UTX-B03/14 UWP-D Bodypack Transmitter with Omnidirectional Lavalier, UC14, 470 to 542 MHz
The UTX-B03 belt-pack transmitter forms part of a complete UWP-D audio system offering the sound quality of digital audio processing combined with the reliability of analogue FM modulation. The UTX-B03 package offers wide frequency coverage with up to 72 MHz bandwidth (depending on region) across a wide range of channels, with a choice of models to choose from. Easy-to-use features include a large display, automatic channel setting function, USB connection for power supply and line input availability. The UWP-D Series system provides superb transient response performance for all ENG / EFP production applications.
Key Features
- UWP-D digital audio processing for high quality sound
- Large display for ease of use
- Wide frequency coverage
- Automatic channel setting
- Compatibility with Sony 800 and UWP Series analogue audio receivers
- True Diversity reception system
- USB for external power supply or charging batteries
- Robust metal body
Technical Specifications
Oscillator Type
Crystal-controlled PLL Synthesizer
Antenna Type
1/4 wave length wire
Type of Emission
F3E
Carrier Frequencies: Americas
14UC: 470.125 MHz to 541.875 MHz (UHF-TV channels 14 to 25) (not available in Brazil)
25UC: 536.125 MHz to 607.875 MHz (UHF-TV channels 25 to 36)
42LA: 638.125 MHz to 697.875 MHz (UHF-TV channels 42-51) (not available in US or Canada)
90UC: 941.500-952.000 MHz, 952.850-956.250 MHz, and 956.45-959.85 MHz
Carrier Frequencies: Europe, UAE, South Africa, Australia, Malaysia, Vietnam, New Zealand
UTX-B03/21: 470.025 MHz to 542.000 MHz (not available in Australia, Malaysia, Vietnam or New Zealand)
UTX-B03/33: 566.025 MHz to 633.000 MHz (not available in New Zealand)
UTX-B03/42: 638.025 MHz to 694.000 MHz
UTX-B03/51: 710.025 MHz to 782.000 MHz (only available in Europe)
Carrier Frequencies: China
UTX-B03/38: 710.025 MHz to 782.000 MHz
Carrier Frequencies: Thailand, Taiwan, Singapore
UTX-B03/E: 794.125 MHz to 805.875 MHz
Carrier Frequencies: Japan
UTX-B03/JB: 806.125 MHz to 809.750 MHz
Carrier Frequencies: South Korea
UTX-B03/KR3: 925.125 MHz to 937.500 MHz
RF Power: Americas, Europe, UAE, South Africa, Australia, Malaysia, Vietnam, New Zealand, China30mW / 5mW
Operating Temperature
0C to 50C
32F to 122F
Storage/Transport Temperature
-20C to +55C
-4F to +131F
Dimensions
63 x 82 x 20 mm (excluding the anntenas) (W x H x D)
Mass
Approx. 149 g (including batteries)
